R190E3-L01 19.0 inch A Grade Brand New LCD Screen Display for CMO
Product Details:
| Place of Origin: | China |
| Brand Name: | CMO |
| Model Number: | R190E3-L01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | R190E3-L01 | Diagonal Size: | 19.0" |
|---|---|---|---|
| Resolution: | 1280(RGB)×1024, SXGA 86PPI | Active Area: | 376.32(W)×301.056(H) Mm |
| Bezel Opening: | 380.2(W)×305.0(H) Mm | Outline Size: | 404.2(W)×330(H) ×35.7(D) Mm |
| Brightness: | 310 Cd/m² (Typ.) | Display Mode: | LCS MVA, Normally Black, Transmissive |
| Panel Weight: | 3.23Kgs (Max.) | Application: | Medical Imaging |
Product Description
R190E3-L01 19.0 inch A Grade Brand New LCD Screen Display for CMO
R190E3-L01 Product details :
| CMO LCD Screen R190E3-L01 | |
|---|---|
| Brand | CMO |
| Model P/N | R190E3-L01 |
| Diagonal Size | 19.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1280(RGB)×1024, SXGA 86PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 376.32(W)×301.056(H) mm |
| Bezel Opening | 380.2(W)×305.0(H) mm |
| Outline Dim. | 404.2(W)×330(H)×27.85(D) mm |
| Treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Luminance | 310 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 5/15 (Typ.)(Tr/Td) |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) |
| Operating Mode | LCS MVA, Normally Black, Transmissive |
| Support Color | 16.7M 74% NTSC |
| Light Source | CCFL [6 pcs] , 50K hours , With Inverter |
| Weight | 3.23Kgs (Max.) |
| Designed For | Medical Imaging |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Power Supply | 5.0V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| R190E3-L01 19.0 inch A Grade Brand New LCD Screen Display for CMO | |
R190E3-L01 Customer Service Policy:
We are more than happy to answer any questions that you have, please contact with
1:Orders processed timely after the payment verification.
2:We only ship to confirmed order addresses. Your order address MUST MATCH your Shipping address.
3:If you have not received your shipment within 30 days from payment, please contact us. We will track the shipment and get back to you as soon as possible with a reply. Our goal is customer satisfaction!
4:Due to stock status and time differences, we will choose to ship your item from our first available warehouse for fast delivery.
R190E3-L01 Shipping and Package :
R190E3-L01 The delivery time is approximately:
US/UK/Australia 7-14 working days.
Canada 7-25 working days.
It may take 7-20 working days for France/Spain/Germany.
Eastern Europe can take up to 16-30 working days.
It may take up to 30-50 working days for Italy/Brazil/South America.
Shipped by DHL Express (it takes 3-6 working days to arrive)
R190E3-L01 Guarantee:
All lcd panel enjoyed 60 days warranty. If you find the lcd is non-workable once you received, pls inform us within 7 days. We reserve the right refusing any requirement that informs the seller longer than 7 days. We will assist you the solve the problem and RMA is acceptable if problem still unsolved after communication.
RMA not acceptable due to ordering the wrong model.
R190E3-L01 FAQ:
Q: Do you accept sample orders of R190E3-L01 ?
A: Of course!sample order is welcome !
Q: How can I trace my order of R190E3-L01 ?
A: we will give you tracking number then you can trace your order from website.
Q: Can you give me a discount if I need a large quantity of R190E3-L01 ?
A: Of course!If you make a large order, we will give you a discount.
Q: How to make payment of R190E3-L01 ?
A: We accept T/T , Paypal , western union .
