HSD123JPW2-C00 12.3 inch TFT LCD Screen 1920*720 LCD Display for Automotive Display
Product Details:
| Place of Origin: | China |
| Brand Name: | HannStar |
| Model Number: | HSD123JPW2-C00 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | HSD123JPW2-C00 | Diagonal Size: | 12.3" |
|---|---|---|---|
| Resolution: | 1920(RGB)×720 167PPI | Active Area: | 292.032(W)×109.512(H) Mm |
| Bezel Opening: | 294.8(W)×112.1(H) Mm | Outline Size: | 308.1(W)×130(H) ×15.6(D) Mm |
| Brightness: | 850 Cd/m² (Typ.) | Contrast Ratio: | 1000:1 (Typ.) (TM) |
| Panel Weight: | 520g (Typ.) | Application: | Automotive Display |
Product Description
HSD123JPW2-C00 12.3 inch TFT LCD Screen 1920*720 LCD Display for Automotive Display
HSD123JPW2-C00 Product details :
| HannStar LCD Screen HSD123JPW2-C00 | |
|---|---|
| Panel Brand | HannStar |
| Model P/N | HSD123JPW2-C00 |
| Diagonal Size | 12.3" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1920(RGB)×720 167PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 292.032(W)×109.512(H) mm |
| Bezel Opening | 294.8(W)×112.1(H) mm |
| Outline Size | 308.1(W)×130(H) ×15.6(D) mm |
| Surface | Antiglare |
| Brightness | 850 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Display Mode | IPS Pro, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 14/16 (Typ.)(Tr/Td) |
| Display Colors | 16.7M 100% sRGB |
| Lamp Type | 11S4P WLED , 30K hours , Without Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 520g (Typ.) |
| Application | Automotive Display |
| Signal Interface | LVDS (2 ch, 8-bit) , 50 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| HSD123JPW2-C00 12.3 inch TFT LCD Screen 1920*720 LCD Display for Automotive Display | |
HSD123JPW2-C00 Description:
1.Highest quality touch LCD screen replacement parts.
2.Reasonable and competitive price.
3.It is used to repair faulty screen, Touch Screen problems, dead pixels, cracked Touch screens, broken etc.
4.Each assembly is tested before shipping and is 100% working;Quality control: All are tested before delivery,No any Dark Spots,Color Point,Deal Pixels.
5.if you have any problem with the item, please contact me before you buy it, we will reply to you as soon as possible.
6. It is shipped in protective bubble wrap and has all the protective screen coatings, so, please do not worry.
HSD123JPW2-C00 Shipping and Package :
HSD123JPW2-C00 About Shipping:
- Please provide the full name of consignee and detailed address for shipping.
- We only ship according to the delivery address in the order, if you want to change the shipping address, please contact me in advance.
- NOTICE: The buyer is responsible for all additional customs fees, brokerage fees, customs duties and taxes imported into your country.
HSD123JPW2-C00 Return& Refund:
Please read the item description and check the pictures carefully before bidding.
Refund or Return is available if the item arrived broken,not as described or does not do what it's supposed to.
Return items must have all original packaging and in good condition.
HSD123JPW2-C00 FAQ:
Q: Can I pay my goods HannStar HSD123JPW2-C00 by credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: How do you ship my goods HSD123JPW2-C00 ?
A: We can shipping all over the world.via DHL,UPS,Fedex and EMS, the packaging is very safe and strong.
Q: I do not find the LCD I am looking for in the website, what should I do ?
A: You can give us some pictures,we have a lot of LCD out of shelves.
Q: What happen if the HannStar HSD123JPW2-C00 I receive can't work ?
A: The HSD123JPW2-C00 will be tested strictly before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel.
