LVDS 15 inch tft lcd screen 1024*768 LQ150X1LW73 lcd panel display CCFL
Product Details:
| Place of Origin: | China |
| Brand Name: | SHARP |
| Model Number: | LQ150X1LW73 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | LQ150X1LW73 | Diagonal Size: | 15.0" |
|---|---|---|---|
| Resolution: | 1024(RGB)*768[XGA] 85PPI | Active Area: | 304.128 * 228.096 Mm (H*V) |
| Outline Size: | 331.6 * 254.76 * 13 Mm (H*V*D) | Contrast Ratio: | 600:1 (Typ.) (TM) |
| Response Time: | 35 (Typ.)(Tr+Td) | Brightness: | 350 Cd/m² (Typ.) |
| Number Of Color: | 16.2M , 70% NTSC | Designed For: | Industrial |
Product Description
LVDS 15 inch tft lcd screen 1024*768 LQ150X1LW73 lcd panel display CCFL
LQ150X1LW73 Product details :
| SHARP LCD SCREEN LQ150X1LW73 | |
| Brand | SHARP |
| Model Name | LQ150X1LW73 |
| Diagonal Size | 15.0 inch |
| Screen type | LCM, a-Si TFT-LCD |
| Resolution | 1024(RGB)×768[XGA] 85PPI |
| Pixel configuration | RGB Vertical Stripe |
| Display size | 304.128 × 228.096 mm (H×V) |
| Bezel Opening | 307.2 × 231.1 mm (H×V) |
| Outline Size | 331.6 × 254.76 × 13 mm (H×V×D) |
| Surface | Matte Hard coating (3H) |
| Brightness | 350 cd/m² (Typ.) |
| Contrast Ratio | 600:1 (Typ.) |
| Viewing angle | 85/85/85/85 (Typ.) (CR≥10) |
| Display Mode | ASV, Normally Black, Transmissive |
| Number of color | 16.2M , 70% NTSC |
| Reaction time | 35 (Typ.)(Tr+Td) |
| Backlight type | WLED ,50K 4hours, with LED driver |
| Refresh rate | 60Hz |
| Touch function | Without |
| Application | Industrial |
| Weight | 1.45kgs (Max.) |
| Signal Interface | LVDS (1 ch,8-bit) , terminal, 20 pins |
| Input Voltage | 3.3V (Typ.) |
| Environment | Storage temperature: -25 ~ 70 °C Operating temperature: -20 ~ 70 °C |
| LVDS 15 inch tft lcd screen 1024*768 LQ150X1LW73 lcd panel display CCFL | |
LQ150X1LW73 NOTE:
Please check your model and screen size and part number again. If you are not sure about the compatibility of this item, please send us the specific model and photo of your original screen;
Usually, the LED panel we send will be a compatible model, which may not be exactly the same as the model of your original screen or inconsistent with the advertising picture in the product, but we can ensure that it is suitable for 100% model.
All items are tested before shipment, excluding tape. If you need a specific model, please leave a message when ordering.
