12.3 inch 1920*720 HSD123JPW3-A13 LCD Monitors Screen Display Parts
Product Details:
| Place of Origin: | China |
| Brand Name: | HannStar |
| Model Number: | HSD123JPW3-A13 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | HSD123JPW3-A13 | Diagonal Size: | 12.3" |
|---|---|---|---|
| Resolution: | 1920(RGB)×720 167PPI | Active Area: | 292.032(W)×109.512(H) Mm |
| Outline Size: | 302(W)×125.4(H) ×14.2(D) Mm | Brightness: | 850 Cd/m² (Typ.) |
| Contrast Ratio: | 1500:1 (Typ.) (TM) | Response Time: | 25 (Typ.)(Tr+Td) |
| Panel Weight: | 345/378g (Typ./Max.) | Application: | Outdoor High Brightness / Automotive Display |
Product Description
12.3 inch 1920*720 HSD123JPW3-A13 LCD Monitors Screen Display Parts
HSD123JPW3-A13 Product details :
| HannStar LCD Screen HSD123JPW3-A13 | |
|---|---|
| Panel Brand | HannStar |
| Model P/N | HSD123JPW3-A13 |
| Diagonal Size | 12.3" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1920(RGB)×720 167PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 292.032(W)×109.512(H) mm |
| Outline Size | 302(W)×125.4(H) ×14.2(D) mm |
| Surface | Glare (Haze 0%), Hard coating |
| Brightness | 850 cd/m² (Typ.) |
| Contrast Ratio | 1500:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Display Mode | IPS Pro, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 25 (Typ.)(Tr+Td) |
| Display Colors | 16.7M 75% NTSC |
| Lamp Type | 11S4P WLED , 30K hours , Without Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 345/378g (Typ./Max.) |
| Application | Outdoor High Brightness / Automotive Display |
| Signal Interface | LVDS (2 ch, 8-bit) , 50 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| 12.3 inch 1920*720 HSD123JPW3-A13 LCD Monitors Screen Display Parts | |
HSD123JPW3-A13 Payment Terms:
We prefer PayPal. And we accept Wire Transfer, Escrow.
HSD123JPW3-A13 Shipping and Package :
HSD123JPW3-A13 Shipping Terms:
1. We ship all the items to your address, please make sure that your address must be correct or send us a message to inform us if you want to change a address before you pay for it.
2. We ship all our buyers packages with tracking number, and all the items will be sent within 1-2 business days after payment received.
3. We Ship it in one day by DHL 1- 3 Day arrive you!
4. For remote regions, we will charge your extra shipping costs. Usually it cost about 35USD-50USD. We will contact you after your payment. Thanks for your understanding.
HSD123JPW3-A13 TERMS OF SALE:
Dear friend, your happy is very important to me!We stand behind every product we sell.Your bid is a contract - Place a bid only if you're serious about buying the item. If you are the winning bidder, you will enter into a legally biding contract to purchase the item. If payment is not received within 7 days, item may be offered to the next highest bidder or relisted at the seller's sole discretion.If you're not pleased with your purchase, we'll be happy to make an exchange or refund the product price less S&H within 7 days of your purchase. For any exchange or refund, we need the original receipt or a record of the purchase in our system, and the product must be in its original condition, including the box, packaging, and all accessories.Shipping and handling charges are not refundable.
HSD123JPW3-A13 FAQ:
Q: How long is the warranty of HSD123JPW3-A13 ?
A: 90days warranty .
Q: Can you give me a discount if I need a large quantity of HSD123JPW3-13 ?
A: Of course!If you make a large order, we will give you a discount.
Q: How can I trace my order of HSD123JPW3-A13 ?
A: we will give you tracking number then you can trace your order from website.
Q: If I order HSD123JPW3-A13 now,when will you ship the goods ?
A: The order will be shipped within 2-3 working days after received your payment.
