15.0 inch 1024*768 85 PPI LQ150X1LW71N LCD display screen
Product Details:
| Place of Origin: | China |
| Brand Name: | SHARP |
| Model Number: | LQ150X1LW71N |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | LQ150X1LW71N | Diagonal Size: | 15.0" |
|---|---|---|---|
| Resolution: | 1024(RGB)×768[XGA] 85PPI | Active Area: | 304.128 × 228.096 Mm (H×V) |
| Outline Size: | 331.6 × 254.76 × 13 Mm (H×V×D) | Viewing Angle: | 85/85/85/85 (Typ.) (CR≥10) |
| Luminance: | 250 Cd/m² (Typ.) | Contrast Ratio: | 400:1 (Typ.) (TM) |
| Number Of Color: | 16.2M , 70% NTSC | Used For: | Industrial |
Product Description
15.0 inch 1024*768 85 PPI LQ150X1LW71N LCD display screen
LQ150X1LW71N Product details :
| SHARP LCD SCREEN LQ150X1LW71N | |
| Brand | SHARP |
| Model Name | LQ150X1LW71N |
| Diagonal Size | 15.0 inch |
| Screen type | LCM, a-Si TFT-LCD |
| Resolution | 1024(RGB)×768[XGA] 85PPI |
| Pixel configuration | RGB Vertical Stripe |
| Display size | 304.128 × 228.096 mm (H×V) |
| Bezel Opening | 307.2 × 231.1 mm (H×V) |
| Outline Size | 331.6 × 254.76 × 13 mm (H×V×D) |
| Treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Brightness | 250 cd/m² (Typ.) |
| Contrast Ratio | 400:1 (Typ.) |
| Viewing angle | 85/85/85/85 (Typ.) (CR≥10) |
| Work Mode | ASV, Normally Black, Transmissive |
| Number of color | 16.2M , 70% NTSC |
| Reaction time | 25 (Typ.)(Tr+Td) |
| Backlight type | WLED ,50K 4hours, with LED driver |
| Refresh rate | 60Hz |
| Touch function | Without |
| Used for | Industrial |
| Mass | 1.30kgs (Max.) |
| Signal Type | LVDS (1 ch,8-bit) , terminal, 20 pins |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage temperature: -25 ~ 70 °C Operating temperature: -20 ~ 70 °C |
| 15.0 inch 1024*768 85 PPI LQ150X1LW71N LCD display screen | |
