LCD screen panel 13.3 inch LCD Module LQ133M1LW02 1920*1080
Product Details:
| Place of Origin: | China |
| Brand Name: | SHARP |
| Model Number: | LQ133M1LW02 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | LQ133M1LW02 | Diagonal Size: | 13.3" |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080 FHD 166PPI | Active Area: | 293.76 × 165.24 Mm (H×V) |
| Outline Size: | 310.6 × 182.2 × 13.1 Mm (H×V×D) | Viewing Angle: | 85/85/85/85 (Typ.)(CR≥10) |
| Luminance: | 450 Cd/m² (Typ.) | Contrast Ratio: | 600:1 (Typ.) (TM) |
| Number Of Color: | 16.7M 86% NTSC | Used For: | Industrial |
Product Description
LCD screen panel 13.3 inch LCD Module LQ133M1LW02 1920*1080
LQ133M1LW02 Product details :
| SHARP LCD SCREEN LQ133M1LW02 | |
| Brand | SHARP |
| Model Name | LQ133M1LW02 |
| Diagonal Size | 13.3 inch |
| Screen type | LCM, a-Si TFT-LCD |
| Resolution | 1920(RGB)×1080 FHD 166PPI |
| Pixel configuration | RGB Vertical Stripe |
| Display size | 293.76 × 165.24 mm (H×V) |
| Outline Size | 310.6 × 182.2 × 13.1 mm (H×V×D) |
| Surface | Antiglare, Hard coating (3H) |
| Brightness | 400 cd/m² (Typ.) |
| contrast | 900:1 (Typ.) |
| Viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| Display Mode | New Mode2, Normally Black, Transmissive |
| Number of color | 16.7M 86% NTSC |
| Reaction time | 30 (Typ.)(Tr+Td) ms |
| Backlight type | WLED , 70K hours , With LED Driv |
| Refresh rate | 60Hz |
| Touch function | Without |
| Weight | 710g(Max.) |
| Application | Gaming |
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Input Voltage | 5.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 80 °C ; Storage Temp.: -20 ~ 80 °C |
| LCD screen panel 13.3 inch LCD Module LQ133M1LW02 1920*1080 | |
LQ133M1LW02 Our advantages:
1: We are all own stock, with adequate supply
2: The quality of the product reached a series of certification
3: We support a variety of transportation, Hong Kong and the Chinese postal packets, EMS.DHL federal .UPS and TNT, can fully meet the different needs of the buyer.
LQ133M1LW02 Payment and Shipment:
1. We accept Alipay, Western Union, T/T, etc. All major credit cards are accepted through secure payment processor ESCROW
2. Item will be shipped out within 1-3 days.
3. Make sure your address is correct (full name is recommended). We are not responsible for any wrong or undeliverable address.
4. We are not responsible for the possibly additional import duties, remote area charges, taxes or other Customs related fee.
5. Delivery time:
--via DHL, Fedex, UPS: 3-7 working days
--via EMS: 7-15 working days
--via Air Mail or Parcel: 10-30 working days (sometimes longer)
LQ133M1LW02 Refund&Return:
1.If the item is defective, pls notify us within 3 days after receiving.
2.Items should be returned with original package if possible.
Gentlehint:Due to regional weather and other factors,thedelivery timeof China Post Ai Mail needs 10 to 50 days. Please be patient when you choose the China Post Air Mail.
LQ133M1LW02 FAQ:
Q: How long is the warranty of LQ133M1LW02 ?
A: 90days warranty .
Q: Can you give me a discount if I need a large quantity of LQ133M1LW02 ?
A: Of course!If you make a large order, we will give you a discount.
Q: If I order LQ133M1LW02 now,when will you ship the goods ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: Do you accept sample orders for LQ133M1LW02 ?
A: Of course!sample order is welcome !
LQ133M1LW02 Shipping and Package :
