CCFL 12.1 inch tft lcd screen 800*600 lcd display panel LQ121S1LG61
Product Details:
| Place of Origin: | China |
| Brand Name: | SHARP |
| Model Number: | LQ121S1LG61 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | LQ121S1LG61 | Diagonal Size: | 12.1" |
|---|---|---|---|
| Resolution: | 800(RGB)×600 SVGA 82PPI | Active Area: | 246 × 184.5 (H×V) Mm |
| Bezel Opening: | 249.0 × 187.5 (H×V) Mm | Outline(mm): | 276 × 209 × 11 (H×V×D) Mm |
| Luminance: | 450 Cd/m² (Typ.) | Contrast Ratio: | 600:1 (Typ.) (TM) |
| Viewing Angle: | 70/70/50/60 (Typ.)(CR≥10) | Used For: | Industrial |
Product Description
CCFL 12.1 inch tft lcd screen 800*600 lcd display panel LQ121S1LG61
LQ121S1LG61 Product details :
| SHARP LCD SCREEN LQ121S1LG61 | |
| Diagonal Size | SHARP |
| Model Name | LQ121S1LG61 |
| Diagonal Size | 12.1inch |
| Screen type | LCM, a-Si TFT-LCD |
| Resolution | 800(RGB)×600 SVGA 82PPI |
| Pixel configuration | RGB Vertical Stripe |
| Display size | 246 × 184.5 (H×V) mm |
| Outline Size | 276 × 209 × 11 (H×V×D) mm |
| Bezel Opening | 249.0 × 187.5 (H×V) mm |
| Contrast | Matte, Hard coating (3H) |
| Brightness | 450 cd/m² (Typ.) |
| Contrast Ratio | 600:1 (Typ.) (Transmission) |
| Viewing angle | 70/70/50/60 (Typ.)(CR≥10) |
| Brightness | TN, Normally White, Transmissive |
| Number of color | 262K , 45% NTSC |
| Reaction time | 10/25 (Typ.)(Tr/Td) ms |
| Backlight type | 2 pcs CCFL,50K hours, |
| Refresh rate | 60Hz |
| Touch function | No touch |
| Designed For | Industrial |
| Panel weight | 800g (Max.) |
| Signal Interface | 20 pins LVDS (1 ch, 6-bit) , terminal |
| Input Voltage | 3.3/5.0V (Typ.) |
| Environment | Storage temperature: -30 ~ 80 °C Operating temperature: -30 ~ 80 °C |
| CCFL 12.1 inch tft lcd screen 800*600 lcd display panel LQ121S1LG61 | |
LQ121S1LG61 Our advantages:
1: We are all own stock, with adequate supply
2: The quality of the product reached a series of certification
3: We support a variety of transportation, Hong Kong and the Chinese postal packets, EMS.DHL federal .UPS and TNT, can fully meet the different needs of the buyer.
LQ121S1LG61 About Us:
1.Our working time: Hong Kong time: Monday to Saturday Everyday 9:00 am to 18:00 pm.
2.Any questions, please contact us via Whatsapp message, In our working hours will be resumed within 48 hours.
3.Our aim is to provide Top Level Customer Service, your recognition will encourage us greatly and serve you better. We strive to keep all our customers satisfy.
LQ121S1LG61 Refund&Return:
1.If the item is defective, pls notify us within 3 days after receiving.
2.Items should be returned with original package if possible.
Gentlehint:Due to regional weather and other factors,thedelivery timeof China Post Ai Mail needs 10 to 50 days. Please be patient when you choose the China Post Air Mail.
LQ121S1LG61 FAQ:
Q: How do you ship my goods LLQ121S1LG61 ?
A: We can shipping all over the world.via DHL,UPS,Fedex and EMS, the packaging is very safe and strong.
Q: How long is the warranty of SHARP LQ121S1LG61 ?
A: 90 days warranty .
Q: How can I trace my order of LQ121S1LG61 ?
A: we will give you tracking number then you can trace your order form website.
Q: Can you give me a discount if I need a large quantity of LQ121S1LG61 ?
A: Of course!If you make a large order, we will give you a discount.
LQ121S1LG61 Shipping and Package :
