HannStar 8.8 Inch LCD Panel HSD088KPW1-A00 1920x480 Lcd Module
Product Details:
| Place of Origin: | China |
| Brand Name: | HannStar |
| Model Number: | HSD088KPW1-A00 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | HSD088KPW1-A00 | Diagonal Size: | 8.8" (Native Bar) |
|---|---|---|---|
| Resolution: | 1920×480(RGB) 222PPI | Active Area: | 218.88(W)×54.72(H) Mm |
| Outline Dim.: | 231.3(W)×64.3(H) ×6.4(D) Mm | Luminance: | 600 Cd/m² (Typ.) |
| Contrast Ratio: | 800:1 (Typ.) (TM) | Response Time: | 40 (Typ.)(Tr+Td) |
| Panel Weight: | 110g (Typ.) | Application: | Stretched Bar LCD / Automotive Display |
| High Light: | HannStar Stretched Bar Lcd Display,600cd Stretched Bar Lcd Display,HSD088KPW1-A00 Stretched Bar Monitor |
||
Product Description
HannStar 8.8 inch LCD panel HSD088KPW1-A00 1920x480 lcd module
HSD088KPW1-A00 Product details :
| HannStar LCD Screen HSD088KPW1-A00 | |
|---|---|
| Panel Brand | HannStar |
| Model P/N | HSD088KPW1-A00 |
| Diagonal Size | 8.8" (Native bar) |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1920×480(RGB) 222PPI |
| Pixel Format | RGB Horizontal Stripe |
| Active Area | 218.88(W)×54.72(H) mm |
| Outline Size | 231.3(W)×64.3(H) ×6.4(D) mm |
| Surface | Hard coating |
| Brightness | 600 cd/m² (Typ.) |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Display Mode | IPS Pro, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 40 (Typ.)(Tr+Td) |
| Display Colors | 16.7M 50% NTSC |
| Lamp Type | WLED , 30K hours , Without Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 110g (Typ.) |
| Application | Stretched Bar LCD / Automotive Display |
| Signal Interface | LVDS (2 ch, 8-bit) , 40 pins Connector |
| Input Voltage | 3.3/12/18/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| Environment | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| HannStar 8.8 inch LCD panel HSD088KPW1-A00 1920x480 lcd module | |
