New IPS 12.1 inch HSD121KXN1-B00 1024*768 lcd Screen panel for Automotive Display
Product Details:
| Place of Origin: | China |
| Brand Name: | HannStar |
| Model Number: | HSD121KXN1-B00 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | HSD121KXN1-B00 | Diagonal Size: | 12.1" |
|---|---|---|---|
| Resolution: | 1024(RGB)×768, XGA 105PPI | Active Area: | 245.76(W)×184.32(H) Mm |
| Luminance: | 600 Cd/m² (Typ.) | Contrast Ratio: | 900:1 (Typ.) (TM) |
| Response Time: | 30 (Typ.)(Tr+Td) | Operating Mode: | IPS Pro, Normally Black, Transmissive |
| Support Color: | 16.7M 72% NTSC | Designed For: | Automotive Display |
Product Description
New IPS 12.1 inch HSD121KXN1-B00 1024*768 lcd Screen panel for Automotive Display
HSD121KXN1-B00 Product details :
| HannStar LCD Screen HSD121KXN1-B00 | |
|---|---|
| Panel Brand | HannStar |
| Model P/N | HSD121KXN1-B00 |
| Diagonal Size | 12.1" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1024(RGB)×768, XGA 105PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 245.76(W)×184.32(H) mm |
| Luminance | 600 cd/m² (Typ.) |
| Contrast Ratio | 900:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 30 (Typ.)(Tr+Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Operating Mode | IPS Pro, Normally Black, Transmissive |
| Support Color | 16.7M 72% NTSC |
| Light Source | WLED , 30K hours , With LED Driver |
| Designed For | Automotive Display |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | LVDS |
| Environment | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C |
| New IPS 12.1 inch HSD121KXN1-B00 1024*768 lcd Screen panel for Automotive Display | |
HSD121KXN1-B00 Friendly Reminder :
- Installation guide is not included,We are not responsible for any damage caused by the installation of this accessory, make sure you understand how to install before ordering.
- Special skills and techniques required for proper installation. We recommend you process your repairment with an assistance of a qualified technician.
- Please make sure you understand disassembly procedure before purchase.It is strongly recommended that customers test the product before installation.
HSD121KXN1-B00 Shipping and Package :
HSD121KXN1-B00 About Shipping:
we will test them strictly before shipping.
we will ship it in 1-3 working days after your paying.we only ship according to the shipping address,if you want to change shipping address,pls contact me in advance in time.as to the shipping time,it usually will be 7-30 days,which will be different for different countries.
HSD121KXN1-B00 Contact us:
The best way to contact with us is via email.
If you have any RFQ, please kindly contact us.We will be your good choice.
Thank you for coming, thank you! wish you a happy life!
HSD121KXN1-B00 FAQ:
Q: How long is the warranty of HSD121KXN1-B00 ?
A: 90days warranty .
Q: Can you give me a discount if I need a large quantity of HSD121KXN1-B00 ?
A: Of course!If you make a large order, we will give you a discount.
Q: If I order HSD121KXN1-B00 now,when will you ship the goods ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: Do you accept sample orders for HSD121KXN1-B00 ?
A: Of course!sample order is welcome !
