12.1 Inch LCD Panel EV121WXM-N12 TFT IPS Display Support Full View Angle 1280*800 Resolution LCD Screen
Product Details:
| Place of Origin: | China |
| Brand Name: | BOE |
| Model Number: | EV121WXM-N12 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | EV121WXM-N12 | Diagonal Size: | 12.1" |
|---|---|---|---|
| Resolution: | 1280(RGB)×800, WXGA 124PPI | Active Area: | 261.12(W)×163.2(H) Mm |
| Bezel Opening: | 264.12(W)×166.2(H) Mm | Outline Dim.: | 277.7(W)×180.6(H)×9.2(D) Mm |
| Luminance: | 500 Cd/m² (Typ.) | Contrast Ratio: | 1200:1 (Typ.) (TM) |
| Mass: | TBD | Used For: | Medical Imaging |
Product Description
12.1 Inch LCD Panel EV121WXM-N12 TFT IPS Display Support Full View Angle 1280*800 Resolution LCD Screen
EV121WXM-N12 Product details :
| BOE LCD Screen EV121WXM-N12 | |
|---|---|
| Brand | BOE |
| Model P/N | EV121WXM-N12 |
| Diagonal Size | 12.1" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1280(RGB)×800, WXGA 124PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 261.12(W)×163.2(H) mm |
| Bezel Opening | 264.12(W)×166.2(H) mm |
| Outline Size | 277.7(W)×180.6(H)×9.2(D) mm |
| Treatment | Antiglare (Haze 25%) |
| Luminance | 500 cd/m² (Typ.) |
| Contrast Ratio | 1200 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Response | 30 (Typ.)(Tr+Td) ms |
| Good View at | Symmetry |
| Work Mode | ADS, Normally Black, Transmissive |
| Color Depth | 262K/16.7M 100% sRGB |
| Backlight | 12S4P WLED , 50K hours , With LED Driver |
| Mass | TBD |
| Used for | Medical Imaging |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| 12.1 Inch LCD Panel EV121WXM-N12 TFT IPS Display Support Full View Angle 1280*800 Resolution LCD Screen | |
EV121WXM-N12 About item and shipping price:
1. For products that are rarely sold or never sold, the item price may not be accurate, please contact me for the correct quote.
2. For remote countries or islands, prices may be inaccurate, high or low, please contact me for the correct quote.
EV121WXM-N12 Shipping and Package :
EV121WXM-N12 Custom Duties & Taxes:
1. Import duties, taxes, and charges are not included in the item price or postage cost. These charges are the buyer's responsibility.
2. Avoiding some unnecessary trouble, please check with your country's customs office to inform us what we should declare its value before shipping.
EV121WXM-N12 After sale service:
1.You have 7 days to contact us and 30 days to return it from the date it was received. lfthis item is in your possession more than 7 days, it is considered used and WE WILL NOTISSUE YOU A REFUND OR REPLACEMENT.There are NO EXCEPTIONS! Shipping cost is bearby both seller and buyer in half.
2.All returned items MUST BE in the original packaging and you MUST PROVIDE us with the shipping tracking number, specific reason for the return, and your po#.
3.We will refund YOUR FULL WINNING BID AMOUNT, upon receipt of the item in its original condition and packaging with all components and accessories included,AFTERBOTH Buyer and Seller cancel the transaction from ALI. OR, you may choose to have a replacement.
4. We will bear all the shipping cost if the product(s) is (are) not as advertised.
5.The buyer will take the return shipping cost , if it is broken by yourself or order the wrong product .
EV121WXM-N12 FAQ:
Q: Can You declare my order of EV121WXM-N12 at a very low value ?
A: Yes , we can . pls inform us before shipping .
Q: How long is the warranty of EV121WXM-N12 ?
A: 90days warranty .
Q: Can you give me a discount if I need a large quantity of EV121WXM-N12 ?
A: Of course!If you make a large order, we will give you a discount.
Q: How can I trace my order of EV121WXM-N12 ?
A: we will give you tracking number then you can trace your order from website.
