8.4 inch 31pins 640*480 tft lcd display screen LQ084V1DG21
Product Details:
| Place of Origin: | China |
| Brand Name: | Sharp |
| Model Number: | LQ084V1DG21 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | LQ084V1DG21 | Diagonal Size: | 8.4" |
|---|---|---|---|
| Resolution: | 640(RGB)×480, VGA, 94PPI | Active Area: | 170.88(W)×129.6(H) Mm |
| Outline Size: | 216(W)×152.4(H)×12.5(D) Mm | Brightness: | 300 Cd/m² |
| Contrast Ratio: | 250 :1 (Typ.) (TM) | Response Time: | 20/40 (Typ.)(Tr/Td) Ms |
| Viewing Angle: | 55/55/55/40 (Typ.)(CR≥10) | Application: | Industrial |
Product Description
8.4 inch 31pins 640*480 tft lcd display screen LQ084V1DG21
LQ064V3DG06 Product details :
| SHARP LCD SCREEN LQ084V1DG21 | |
| Brand | SHARP |
| Model Name | LQ084V1DG21 |
| Diagonal Size | 8.4inch |
| Screen type | LCM, a-Si TFT-LCD |
| Resolution | 640(RGB)×480, VGA, 94PPI |
| Pixel configuration | RGB Vertical Stripe |
| Display size | 170.88(W)×129.6(H) mm |
| Outline Size | 216(W)×152.4(H)×12.5(D) mm |
| Bezel Opening | 175.9(W)×134.6(H) mm |
| Contrast | Antiglare (Haze 28%), Hard coating (3H), Antireflection |
| Display | 300 cd/m² (Typ.) |
| Contrast Ratio | 250:1 (Typ.) (Transmission) |
| Viewing angle | 55/55/55/40 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Number of color | 262K |
| Best View on | 12 o'clock |
| Reaction time | 20/40 (Typ.)(Tr/Td) ms |
| Backlight type | CCFL [1 pcs] , 50K hours, |
| Refresh rate | 60Hz |
| Touch function | Without |
| Application | Industrial |
| Panel weight | 430g (Typ./Max.) |
| Signal | LVDS (1 ch, 6-bit) , 31 pins , terminal |
| Input Voltage | 3.3/5.0V (Typ.) |
| Environment | Storage temperature: -30 ~ 80 °C Operating temperature: -30 ~ 80 °C |
| 8.4 inch 31pins 640*480 tft lcd display screen LQ084V1DG21 | |
