LQ057Q3DC12 5.7inch 320x240 lcd display panel for Industrial
Product Details:
| Place of Origin: | China |
| Brand Name: | Sharp |
| Model Number: | LQ057Q3DC12 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | LQ057Q3DC12 | Diagonal Size: | 5.7" |
|---|---|---|---|
| Resolution: | 320×240(RGB), QVGA 70PPI | Active Area: | 115.2(W)×86.4(H) Mm |
| Outline Size: | 144(H)×104.6(V) ×13.5(D) Mm | Brightness: | 500 Cd/m² |
| Contrast Ratio: | 350:1 (Typ.) (TM) | Response Time: | 8/21 (Typ.)(Tr/Td) |
| Viewing Angle: | 65/65/65/40 (Typ.)(CR≥5) | Application: | Industrial |
Product Description
LQ057Q3DC12 5.7inch 320x240 lcd display panel for Industrial
LQ057Q3DC12 Product details :
| Sharp LCD SCREEN LQ057Q3DC12 | |
| Brand | Sharp |
| Model Name | LQ057Q3DC12 |
| Diagonal Size | 5.7inch |
| Screen type | a-Si TFT-LCD , LCM |
| Resolution | 320×240(RGB), QVGA 70PPI |
| Pixel Format | RGB Vertical Stripe |
| Display size | 115.2(W)×86.4(H) mm |
| Outline Size | 144(H)×104.6(V) ×13.5(D) mm |
| Bezel Opening | 121.0(W)×92.2(H) mm |
| Surface | Hard coating (3H) |
| Brightness | 500 cd/m² (Typ.) |
| Contrast | 350:1 (Typ.) (TM) |
| Best angle | 12 o'clock |
| Optical mode | TN, Normally White, Transmissive |
| Viewing angle | 65/65/65/40 (Typ.)(CR≥5) |
| Responding time | 8/21 (Typ.)(Tr/Td) |
| Backlight type | CFL [1 pcs] , 50K hours , W/O Driver |
| Support Color | 262K |
| Panel weight | 210g (Max.) |
| Apply to | Industrial |
| Refresh rate | 60Hz |
| Touch function | Without |
| Signal Interface | Parallel RGB (1 ch, 6-bit) , 33 pins Connector |
| Supply voltage | 3.3V (Typ.)(VCC) |
| Maximum rating | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
| LQ057Q3DC12 5.7inch 320x240 lcd display panel for Industrial | |
LQ057Q3DC12 Customer Service Policy:
We are more than happy to answer any questions that you have, please contact with
1:Orders processed timely after the payment verification.
2:We only ship to confirmed order addresses. Your order address MUST MATCH your Shipping address.
3:If you have not received your shipment within 30 days from payment, please contact us. We will track the shipment and get back to you as soon as possible with a reply. Our goal is customer satisfaction!
4:Due to stock status and time differences, we will choose to ship your item from our first available warehouse for fast delivery.
LQ057Q3DC12 Return& Refund:
Please read the item description and check the pictures carefully before bidding.
Refund or Return is available if the item arrived broken,not as described or does not do what it's supposed to.
Return items must have all original packaging and in good condition.
LQ057Q3DC12 Payment terms:
Credit Card, L/C, PayPal, western union, Bank Transfer, T/T, BOLETO, ESCROW, Mastercard, VISA, e-checking etc.
LQ057Q3DC12 About Shipping:
We will test them strictly before shipping.
We will ship it in 3 working days after your paying.Buyer is responsible for customs duty fee.
It usually takes 10-45 business days for international shipping.If you don't receive the parcel for a long time,pls contact with us.
LQ057Q3DC12 Friendly Reminder :
We provide a wide variety of LCD screens, touch screens, inverters and other accessories.
Many of the original LCD screen has been discontinued, we sell the Used ones of great working condition.
If you are not sure whether the product is the one you need or if you need more, please contact me before ordering.
LQ057Q3DC12 FAQ:
Q: Are you manufactory or trade company?
A: We are a Trade Company , We are LCD panel professional
Q: How to order AUO Display LCD LQ057Q3DC12 ?
A: We accept T/T , Paypal , western union .
Q: Can you tested the LQ057Q3DC12 before shipping ?
A: Of course , our lcd panel LQ057Q3DC12 was Strictly tested before shipping.
Q: What happen if the lcd pane LQ057Q3DC12 received can't work ?
A: AUO Display LQ057Q3DC12 was tesed before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel .
LQ057Q3DC12 Shipping and Package :
