23.0 inch 1920*1080 TFT TFT LCD Panel HV230FH2-600
Product Details:
| Place of Origin: | China |
| Brand Name: | BOE |
| Model Number: | HV230FH2-600 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | HV230FH2-600 | Diagonal Size: | 23.0" |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080, FHD 95PPI | Active Area: | 509.184(W)×286.416(H) Mm |
| Outline Size: | 525.5(W)×301.5(H) Mm | Brightness: | 0 Cd/m² |
| Contrast Ratio: | 1000:1 (Typ.) (TM) | Response Time: | 14 (Typ.)(G To G) |
| Light Source: | No B/L , W/O Driver | Application: | Digital Signage、Transparent Display |
Product Description
23.0 inch 1920*1080 TFT TFT LCD Panel HV230FH2-600
HV230FH2-600 Product details :
| Brand | BOE |
| Model P/N | HV230FH2-600 |
| Diagonal Size | 23.0" |
| Panel Type | a-Si TFT-LCD, CELL, FOB |
| Resolution | 1920(RGB)×1080, FHD 95PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 509.184(W)×286.416(H) mm |
| Bezel Opening | - |
| Outline Dim. | 525.5(W)×301.5(H) mm |
| Luminance | 0 cd/m² |
| View Direction | Symmetry |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Plate Thickness | - |
| Support Color | 16.7M |
| Weight | 660g (Typ.) |
| Frame Rate | 60Hz |
| Treatment | Clear |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Response Time | 14 (Typ.)(G to G) |
| Operating Mode | ADS, Normally Black, Transmissive |
| Transmittance | 4.3% (Typ.)(with Polarizer) |
| Light Source | No B/L , W/O Driver |
| Designed For | Digital Signage,Transparent Display |
| Touch Panel | Without |
| D-IC Detail | COF Built-in 6 source + 3 gate chips |
| Interface Type | LVDS (2 ch, 8-bit)30 pins Connector |
| Power Supply | 5.0V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C; Storage Temperature: -20 ~ 60 °C |
HV230FH2-600 Payment terms:
Credit Card, L/C, PayPal, western union, Bank Transfer, T/T, BOLETO, ESCROW, Mastercard, VISA, e-checking etc.
HV230FH2-600 SHIPPING:
1 We will ship the items within 1-3working days after the payment is reached.
2 We often ship to customers by UPS/DHL/Fedex and ect,We would like to ship to you which is convenient to you. Please contact us directly and we will use your preferred ways.
3 We are not responsible for any accidents, delays or other issues that we couldn’t control, But we will contact the shipping company which is our long term cooperation.
4 Any import fees or charges are the buy’s responsibility.
We have large stock and perfect service, so if you have any RFQ, please kindly contact us.
Look forward your order.
HV230FH2-600 Return:
(1). We accept replacement or exchange within 30 days.
(2). Please keep the goods in the same condition we offered when the buyer return the goods to us .
(3). We will resent the goods to buyer in time if happen that goods broken or doesn't work
HV230FH2-600 FAQ:
Q: Can you give me a discount if I need a large quantity of HV230FH2-600 ?
A: Of course!If you make a large order, we will give you a discount.
Q: Can You declare my order of HV230FH2-600 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: How to make payment of HV230FH2-600 ?
A: We accept T/T , Paypal , western union .
Q: How long is the warranty ?
A: We offer 90 days warranty .
HV230FH2-600 Shipping and Package :
