LCD Screen Display Panel

10.4 inch Sharp LQ10D368 LCD TFT Display Screen 640x480

All Category

Floor Standing Digital Signage

10.4 inch Sharp LQ10D368 LCD TFT Display Screen 640x480

Brand Name:	Sharp
Model Number:	LQ10D368
MOQ:	10pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

LQ10D368

Diagonal Size:

10.4"

Resolution:

640(RGB)×480, VGA 76PPI

Active Area:

211.2(W)×158.4(H) Mm

Outline Size:

246.5(H)×179.4(V) ×11(D) Mm

Brightness:

200 Cd/m² (Typ.)

Viewing Angle:

70/70/40/70 (Typ.)(CR≥10)

Contrast Ratio:

300:1 (Typ.) (TM)

Touch Panel:

20/40 (Typ.)(Tr/Td)

Application:

Industrial

Supply Ability:

100000 Unit/Units per Month

Product Description

10.4 inch Sharp LQ10D368 LCD TFT Display Screen 640x480

LQ10D368 Product details :

Sharp LCD SCREEN LQ10D368
manufacturer	Sharp
Model Name	LQ10D368
Panel Size	10.4 inch
Panel Type	a-Si TFT-LCD, LCM
Resolution	640(RGB)×480, VGA 76PPI
Pixel Format	RGB Vertical Stripe
Active Area	211.2(W)×158.4(H) mm
Outline Dim.	246.5(H)×179.4(V) ×11(D) mm
Bezel Opening	214.6(W)×162.4(H) mm
Treatment	Antiglare, Hard coating (3H)
Brightness	200 cd/m² (Typ.)
Contrast Ratio	300:1 (Typ.) (TM)
View Direction	6 o'clock
Viewing Angle	70/70/40/70 (Typ.)(CR≥10)
Response Time	20/40 (Typ.)(Tr/Td)
Display Mode	STN, Normally Black, Transmissive
Display Colors	262K
Lamp Typec	CCFL [1 pcs] , 50K hours , W/O Driver
Designed For	Industrial
Panel Weight	520g (Max.)
Touch Panel	Without
Interface Type	Parallel RGB (1 ch, 6-bit) , 31 pins Connector
Input Voltage	3.3/5.0V (Typ.)(VCC)
Environment	Operating Temperature: -10 ~ 65 °C ; Storage Temperature: -30 ~ 70 °C
10.4 inch Sharp LQ10D368 LCD TFT Display Screen 640x480

LQ10D368 Customer Service Policy:

We are more than happy to answer any questions that you have, please contact with

1:Orders processed timely after the payment verification.

2:We only ship to confirmed order addresses. Your order address MUST MATCH your Shipping address.

3:If you have not received your shipment within 30 days from payment, please contact us. We will track the shipment and get back to you as soon as possible with a reply. Our goal is customer satisfaction!

4:Due to stock status and time differences, we will choose to ship your item from our first available warehouse for fast delivery.

LQ10D368 About Shipping:

We will test them strictly before shipping.

We will ship it in 3 working day after your paying.we only ship according to the shipping address,if you want to change shipping address,pls contact me inadvance in time.as to the shipping time,it usually will be 7-30 days,which will be differentfor different countries.

LQ10D368 Packing:

Outer packing is strong carton , inner packing is foam , it will be strong and safe enough , to avoid getting broken in the transport .

LQ10D368 Warranty:

Quality assurance is provided.If you feel disappointed with the item,tell us within 7 days of delivery.Items must be returned in original condition for refund/exchange.Shipping cost incurred is on you.We understand the frustrations you might have,please contact us before opening any dispute or leaving any neutral/negative feedback.We card about each buyer and will do our endeavor to fix any problem in a good business manner.Your satisfaction is always our NO.1 priority.

LQ10D368 FAQ:

Q: If I place order now,when will you ship the goods of LQ10D368 ?

A: The order will be shipped within 2-3 working days after received your payment.

Q: How to make payment of LQ10D368 ?

A: We accept T/T , Paypal , western union .

Q: Do you accept sample orders of LQ10D368 ?

A: Of course!sample order is welcome !

Q: Can I pay my order ofLQ10D368 via credit card ?

A: Yes!you can use your credit card through your Paypal account.

LQ10D368 Shipping and Package :
