7.0 inch 11024*600 lcd Screen display HSD0702FW1-A00 for Netbook PC
Product Details:
| Place of Origin: | China |
| Brand Name: | HannStar |
| Model Number: | HSD0702FW1-A00 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | HSD0702FW1-A00 | Diagonal Size: | 7.0" |
|---|---|---|---|
| Resolution: | 1024(RGB)×600, WSVGA 170PPI | Active Area: | 153.6(W)×86.64(H) Mm |
| Outline Size: | 162.5(W)×97.89(H) ×0.8(D) Mm | Surface: | Without Polarizer |
| Brightness: | 0 Cd/m² | Contrast Ratio: | 700:1 (Typ.) (TM) |
| Display Colors: | 16.2M 50% NTSC | Application: | Netbook PC |
Product Description
7.0 inch 11024*600 lcd Screen display HSD0702FW1-A00 for Netbook PC
HSD0702FW1-A00 Product details :
| HannStar LCD Screen HSD0702FW1-A00 | |
|---|---|
| Panel Brand | HannStar |
| Model P/N | HSD0702FW1-A00 |
| Diagonal Size | 7.0" |
| Panel Type | a-Si TFT-LCD, CELL , Q-CUT (Full Cell) |
| Resolution | 1024(RGB)×600, WSVGA 170PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 153.6(W)×86.64(H) mm |
| Outline Size | 162.5(W)×97.89(H) ×0.8(D) mm |
| Surface | Without Polarizer |
| Brightness | 0 cd/m² |
| Contrast Ratio | 700:1 (Typ.) (TM) |
| Viewing Angle | 70/70/60/70 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Best View on | 6 o'clock |
| Response Time | 4/12 (Typ.)(Tr/Td) |
| Glass Depth | 0.40+0.40 mm |
| Transmissivity | 4.11% (Typ.)(with Polarizer) |
| Display Colors | 16.2M 50% NTSC |
| Lamp Type | No B/L |
| Frequency | 60Hz |
| Touch Screen | Without |
| Application | Netbook PC |
| Driver IC | COG Suggest NT51008 + NT52003 |
| Signal Interface | TTL/RSDS |
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| 7.0 inch 11024*600 lcd Screen display HSD0702FW1-A00 for Netbook PC | |
HSD0702FW1-A00 Regarding customs duties and VAT:
Duties and import charges are the responsibility of the buyer. We are not responsible for customs delays or any duties, duties, value added tax (VAT) or other charges that you may incur with your purchase. Please know your customs policy
HSD0702FW1-A00 Shipping and Package :
HSD0702FW1-A00 About Shipping:
we will test them strictly before shipping.
we will ship it in 3 working day after your paying.we only ship according to the shipping address,if you want to change shipping address,pls contact me inadvance in time.as to the shipping time,it usually will be 7-30 days,which will be differentfor different countries.
HSD0702FW1-A00 Guarantee:
1. We will test these items to ensure they work properly, with a 6-month warranty
2. We are a professional supplier and have been working for nearly 10 years.
3. If you have any questions or assistance, please contact us and we will answer you within 24 hours.
HSD0702FW1-A00 FAQ:
Q: How long will I receive my goods HSD0702FW1-A00 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: How long is the warranty ?
A: We offer 90days warranty .
Q: Can You declare my order of HSD0702FW1-A00 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: Can I pay my order of HSD0702FW1-A00 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
