7.0 inch 800*480 Resolution original LCD screen display panel HSD070IDW5-A10
Product Details:
| Place of Origin: | China |
| Brand Name: | HannStar |
| Model Number: | HSD070IDW5-A10 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | HSD070IDW5-A10 | Diagonal Size: | 7.0" |
|---|---|---|---|
| Resolution: | 800(RGB)×480, WVGA 133PPI | Active Area: | 157.2(W)×82.32(H) Mm |
| Bezel Opening: | 160.2(W)×85.32(H) Mm | Outline(mm): | 167(W)×93(H)×6.1(D) |
| Luminance: | 450 (Typ.)(cd/m²) | Contrast Ratio: | 500 : 1 (Typ.) (TM) |
| Mass: | 142g (Typ.) | Used For: | Automotive Display |
Product Description
7.0 inch 800*480 Resolution original LCD screen display panel HSD070IDW5-A10
HSD070IDW5-A10 Product details :
| HannStar LCD Screen HSD070IDW5-A10 | |
|---|---|
| Panel Brand | HannStar |
| Model P/N | HSD070IDW5-A10 |
| Diagonal Size | 7.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 800(RGB)×480, WVGA 133PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 157.2(W)×82.32(H) mm |
| Bezel Opening | 160.2(W)×85.32(H) mm |
| Outline(mm) | 167(W)×93(H)×6.1(D) |
| Treatment | Antiglare |
| Luminance | 450 (Typ.)(cd/m²) |
| Contrast Ratio | 500 : 1 (Typ.) (TM) |
| Viewing Angle | 75/75/60/70 (Typ.)(CR≥10) |
| Work Mode | TN, Normally White, Transmissive |
| Good View at | 6 o'clock |
| Response | 4/12 (Typ.)(Tr/Td) ms |
| Color Depth | 262K/16.7M 53% NTSC |
| Backlight | 3S10P WLED , 20K hours , No Driver |
| Mass | 142g (Typ.) |
| Used for | Automotive Display |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | Parallel RGB (1 ch, 6/8-bit) , 60 pins Connector |
| Voltage Supply | 3.0/10.0/15/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| 7.0 inch 800*480 Resolution original LCD screen display panel HSD070IDW5-A10 | |
HSD070IDW5-A10 Payment:
Your order should be paid within 3 days to avoid the cancellation of the order.
You can pay your order via ESCROW, the leading three-party online payment platform. Escrow allows you to pay securely online without exposing your credit card details. Your payment is only released to us after you confirm satisfactory receipt of your order. Escrow is fast, free and easy to use.
Currently, the payment methods supported by Escrow include Moneybookers, Visa, MasterCard, Western Union, Qiwi and bank transfer. You can also pay with select debit cards including Maestro, Solo, Carte Bleue, PostePay, CartaSi, 4B and Euro6000.
For more information about ESCROW, please contact us.
HSD070IDW5-A10 Shipping and Package :
HSD070IDW5-A10 About Shipping:
we will test them strictly before shipping.
we will ship it in 1-3 working days after your paying.we only ship according to the shipping address,if you want to change shipping address,pls contact me in advance in time.as to the shipping time,it usually will be 7-30 days,which will be different for different countries.
HSD070IDW5-A10 Delivery time is approx:
United States / United Kingdom / Australia 7-14 working days.
Canada 7-25 working days.
France / Spain / Germany may take 7-20 working days.
Eastern Europe may take up to 16-30 working days.
Italy / Brazil / South America may take up to 30-50 working days.
Shipped by DHL Express (Need 3-6 working days to arrive)
HSD070IDW5-A10 FAQ:
Q: How long is the warranty ?
A: We offer 90days warranty .
Q: If I place order now,when will you ship the goods of HSD070IDW5-A10 ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: Can You declare my order of HSD070IDW5-A10 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: How to make payment of HSD070IDW5-A10 ?
A: We accept T/T , Paypal , western union .
