LCD Screen Display Panel

LCD Module Display 19 inch 1280*1024 G190EG01 V0 for Industrial

All Category

Floor Standing Digital Signage

LCD Module Display 19 inch 1280*1024 G190EG01 V0 for Industrial

Brand Name:	AUO
Model Number:	G190EG01 V0
MOQ:	10pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

G190EG01 V0

Diagonal Size:

19.0"

Resolution:

1280(RGB)×1024SXGA 86PPI

Active Area:

376.32(H)×301.056(V) Mm

Outline Size:

396(H)×324(V)×15.8(D) Mm

Response Time:

3.6/1.4 (Typ.)(Tr/Td), 8 (Typ.)(G To G)

Brightness:

450 Cd/m² (Typ.)

Contrast Ratio:

1000 : 1 (Typ.) [Transmission]

Display Colors:

95.0g 16.7M , 72% NTSCMax.)

Application:

Industrial

Supply Ability:

100000 Unit/Units per Month

Product Description

LCD Module Display 19 inch 1280*1024 G190EG01 V0 for Industrial

G190EG01 V0 Product details :

AUO LCD SCREEN G190EG01 V0
Panel Brand	AUO
Panel Model	G190EG01 V0
Panel Size	19.0 inches
Panel Type	a-Si TFT-LCD , LCM
Resolution	1280(RGB)×1024SXGA 86PPI
Pixel Format	RGB Vertical Stripe
Display Area	376.32(H)×301.056(V) mm
Bezel Opening	380.32(H)×305.06(V) mm
Outline Size	396(H)×324(V)×15.8(D) mm
Surface	Matte, Hard coating (3H)
Brightness	450 (Typ.)
Contrast Ratio	1000 : 1 (Typ.) [Transmission]
Viewing Angle	85/85/80/80 (Typ.) (CR≥10)
Display Mode	TN, Normally White, Transmissive
Response Time	3.6/1.4 (Typ.)(Tr/Td), 8 (Typ.)(G to G)
Display Colors	16.7M , 72% NTSC
Lamp Type	4 pcs CCFL , 50K hours, no driver
Frequency	60Hz
Touch Screen	Without
Application	Industrial
Panel Weight	2.40Kgs (Typ.)
Signal Interface	LVDS (2 ch, 8-bit) , terminal, 30 pins
Input Voltage	5.0V (Typ.)
Environment	Storage temperature: -20 ~ 60 °C Operating temperature: 0 ~ 60 °C
LCD Module Display 19 inch 1280*1024 G190EG01 V0 for Industrial

G190EG01 V0 Attentions :

All the items are easy to be fragile ,please test it before installation.

can't be accept the return screen which attmept has been made .

G190EG01 V0 About transportation:

*We will ship the goods within 1-2 working days after you make the payment. We only ship according to the delivery address. If you want to change the delivery address, please contact me in advance.

*We use the fastest shipping service based on the shipping cost you pay. The transit time is usually 7-30 days and may vary by country/region. Delivery to most European, North American and Asian countries within 7-15 days. Up to 30-45 days in other countries. Provide express service (DHL/FEDEX/TNT/ARAMEX/UPS)

G190EG01 V0 Shipping :

1, Shipping via China Post Registered Air Mail or ePacket.

2, We will send out your goods within 3 working days after we get your order .

3, Normally , you can get the goods within 27 calendar days .

4, Please make sure your shipping information ( including address / post code / phone number / contact person ) are correct before order . If you want us send it to another address , pls inform us in advance , and leave message in our transaction.

G190EG01 V0 FAQ:

Q: Can I pay my goods G190EG01 V0 by credit card ?

A: Yes!you can use your credit card through your Paypal account.

Q: Can you give me a discount if I need a large quantity of G190EG01 V0 ?

A: Of course!If you make a large order, we will give you a discount.

Q: Do you accept sample orders for G190EG01 V0 ?

A: Of course!sample order is welcome !

Q: How to make payment for G190EG01 V0 ?

A: We accept T/T , Paypal , western union .

G190EG01 V0 Shipping and Package :

LCD Module Display 19 inch 1280*1024 G190EG01 V0 for Industrial 0
