12.1 Inch LVDS 30pins FHD Laptop Panel HSD121PHW1-A03 LCD Display

12.1 Inch LVDS 30pins FHD Laptop Panel HSD121PHW1-A03 LCD Display

Product Details:

Place of Origin: China
Brand Name: HannStar
Model Number: HSD121PHW1-A03

Payment & Shipping Terms:

Minimum Order Quantity: 1 pcs
Price: Negotiable
Packaging Details: Original packaging/conventional packaging box
Delivery Time: 7 Days
Payment Terms: T/T, Western Union
Supply Ability: 100000 Unit/Units per Month
Get Best Price Contact Now

Detail Information

Model Name: HSD121PHW1-A03 Diagonal Size: 12.1"
Resolution: 1366(RGB)×768, WXGA 129PPI Display Size: 268.01(W)×150.68(H) Mm
Bezel Opening: 271.01(W)×153.48(H) Mm Outline Size: 279(W)×167.2(H) ×5.1(D) Mm
Brightness: 200 Cd/m² (Typ.) Contrast Ratio: 500:1 (Typ.) (TM)
Shape Style: Wedge (PCBA Bent, T≥5.2mm) Application: Laptop
High Light:

LVDS FHD Laptop Panel

,

30pins FHD Laptop Panel

,

HSD121PHW1-A03 LCD Display Panel

Product Description

12.1 Inch LVDS 30pins FHD Laptop Panel HSD121PHW1-A03 LCD Display



12.1 inch LVDS 30pins HD laptop lcd screen HSD121PHW1-A03 LCD display panel


HSD121PHW1-A03 Product details :

HannStar LCD Screen HSD121PHW1-A03
Panel Brand HannStar
Model P/N HSD121PHW1-A03
Diagonal Size 12.1"
Panel Type a-Si TFT-LCD, LCM
Resolution 1366(RGB)×768, WXGA 129PPI
Pixel Format RGB Vertical Stripe
Active Area 268.01(W)×150.68(H) mm
Bezel Opening 271.01(W)×153.48(H) mm
Outline Size 279(W)×167.2(H) ×5.1(D) mm
Surface Glare (Haze 0%), Hard coating (3H)
Brightness 200 cd/m² (Typ.)
Contrast Ratio 500:1 (Typ.) (TM)
Viewing Angle 45/45/15/35 (Typ.)(CR≥10)
Display Mode TN, Normally White, Transmissive
Best View on 6 o'clock
Response Time 3/9 (Typ.)(Tr/Td)
Display Colors 262K 49% NTSC
Lamp Type WLED , 10K hours , With LED Driver
Frequency 60Hz
Touch Screen Without
Shape Style Wedge (PCBA Bent, T≥5.2mm)
Application Laptop
Signal Interface LVDS (1 ch, 6-bit) , 30 pins Connector
Input Voltage 3.3V (Typ.)
Environment Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
12.1 inch LVDS 30pins HD laptop lcd screen HSD121PHW1-A03 LCD display panel



HSD121PHW1-A03 Payment:



· We only accept payment by paypal.



· Please make the payment within 5 days after auction. An unpaid item dispute might be opened if payment have not been received within 5 days.



· The price can be negotiable depending on the purchase quantity.



· Please contact us if you have any questions of payment procedures.


HSD121PHW1-A03 Shipping and Package :
12.1 Inch LVDS 30pins FHD Laptop Panel HSD121PHW1-A03 LCD Display 0



HSD121PHW1-A03 Shipping:



(Please note:business/working days:NOT including the weekend nor the holidays.)



1.We will ship the item via Registered Airmail in 2 business days after the payment cleared.The shipping time of the following sometimes maybe a little longer due to custom problems,holidays or something uncertain reasons.



To most of the countries: 10-25 business days (such as Germany, Spain, Swden, Switzerland etc.)


To the USA, UK and Australia: 7-18 business days


To Russia: 25-60 business days due to Russia post is very slow


For faster delivery,please contact us for express details.


2.We ship your parcel worldwide as gift,the shipping address as according to your paypal address.Please make sure your shipping address is the right one.


3.The package are safe with signature required.If none sign for the package,it will be return.Please don't forget to go to post office to pick it up.Thanks.



HSD121PHW1-A03 Terms:


Please pay attention to:



1.The Return Policy. The item is under warranty duration as specified in the sale; between 7-60 days (This is the time frame warranty which you can return the product for replacement and / or refund ).



2. Return shipping is at the Purchaser's expense, unless the item was received damaged or does not conform to the Seller's description (asked for RMA Number).



3. Please examine the pictures and read the descriptions before placing a bid .



4. The item(s) will be sent only to the address specified in PayPal; please update your address after purchasing the item, or send us a message.



5. We update the tracking on PayPal and eBay. If you experience difficulty in tracking the item, please contact us and we will be happy to provide assistance.



6. If you decide to return the item for any reason, please contact us before sending it, so we can confirm that all details are correct. This will expedite arrival time.



7. Please return the original item you purcha



HSD121PHW1-A03 FAQ:



Q: How long is the warranty ?

A: We offer 90days warranty .



Q: Do you accept sample orders of HSD121PHW1-A03 ?

A: Of course!sample order is welcome !



Q: How to make payment of HSD121PHW1-A03 ?

A: We accept T/T , Paypal , western union .



Q: Can I pay my order of HSD121PHW1-A03 via credit card ?

A: Yes!you can use your credit card through your Paypal account.
