21.3 Inch 1600*1200 TFT LCD Screen Panel G213UAN01.0 Medical Tft Display
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | G213UAN01.0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | G213UAN01.0 | Diagonal Size: | 21.3" |
|---|---|---|---|
| Resolution: | 1600(RGB)×1200, UXGA 94PPI | Active Area: | 432(W)×324(H) Mm |
| Bezel Opening: | 436(W)×328(H) Mm | Outline Size: | 456(W)×349.5(H) Mm |
| Brightness: | 500 Cd/m² (Typ.) | Contrast Ratio: | 1800:1 (Typ.) (TM) |
| Weight: | 2.30Kgs (Typ.) | Application: | Industrial / Medical Imaging |
| High Light: | Medical TFT LCD Screen Panel,21.3 Inch TFT LCD Screen Panel,G213UAN01.0 Medical Tft Display |
||
Product Description
21.3 Inch 1600*1200 TFT LCD Screen Panel G213UAN01.0 Medical Tft Display
21.3 Inch 1600*1200 LCD Panel TFT 16.7M Color G213UAN01.0 For Medical Imaging
G213UAN01.0 Product details :
| AUO LCD Screen G213UAN01.0 | |
|---|---|
| Brand | AUO |
| Model P/N | G213UAN01.0 |
| Diagonal Size | 21.3" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1600(RGB)×1200, UXGA 94PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 432(W)×324(H) mm |
| Bezel Opening | 436(W)×328(H) mm |
| Outline Size | 456(W)×349.5(H) mm |
| Surface | Antiglare |
| Brightness | 500 cd/m² (Typ.) |
| Contrast Ratio | 1800:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Display Mode | AHVA, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 8/8 (Typ.)(Tr/Td) |
| Display Colors | 16.7M 100% sRGB |
| Lamp Type | 13S6P WLED , 50K hours , Without Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Weight | 2.30Kgs (Typ.) |
| Application | Industrial / Medical Imaging |
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Input Voltage | 12.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| 21.3 Inch 1600*1200 LCD Panel TFT 16.7M Color G213UAN01.0 For Medical Imaging | |
G213UAN01.0 Before order:
Before the order, please confirm whether your machine model matching with this LCD screen, if not sure, please contact us
G213UAN01.0 Shipping and Package :
G213UAN01.0 International Orders:
1.Buyer is responsible for all customs fees and import taxes.
2.International orders may take several weeks longer than expected to arrive due to delays in customs processing.
3.And to send to Japan or South Korea via Fedex or DHL , we to declare actual price,the South Korea recipient needs to provide a customs clearance serial number, for example: "P123456789123" . Please provide us with the customs clearance serial number.
G213UAN01.0 ESTIMATED DELIVERY TIME:
- Economy: 15-50 days
- Standard: 10-35 days
- Expedited: 4-7 days
G213UAN01.0 FAQ:
Q: How can I trace my order of G213UAN01.0 ?
A: we will give you tracking number then you can trace your order from website.
Q: If I place order now,when will you ship the goods of G213UAN01.0 ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: How long is the warranty ?
A: We offer 90 days warranty .
Q: Can I pay my order of G213UAN01.0 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
