46 Inch Digital Signage LCD Video Wall Display 1366*768 Module
Product Details:
| Place of Origin: | China |
| Brand Name: | Samsung |
| Model Number: | LTI460WT-L17 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | LTI460WT-L17 | Diagonal Size: | 46" |
|---|---|---|---|
| Resolution: | 1366(RGB)×768, WXGA 34PPI | Active Area: | 1018.35(W)×572.544(H) Mm |
| Bezel Opening: | 1024.4(W)×578.6(H) Mm | Outline Size: | 1047.4(W)×600.6(H) ×59.3(D) Mm |
| Brightness: | 700 Cd/m² (Typ.) | Contrast Ratio: | 1200:1 (Typ.) (TM) |
| Videowall Seam: | 29.0 Mm (active To Active Seam) | Application: | Digital Signage / Video Wall |
| High Light: | Digital Signage LCD Video Wall,LTI460WT-L17 LCD Video Wall,Digital Signage 46 Inch LCD Screen |
||
Product Description
46 Inch Digital Signage LCD Video Wall Display 1366*768 Module
LTI460WT-L17 Original 46.0 inch 1366*768 LCD Screen Display Module for Digital Signage
LTI460WT-L17 Product details :
| Samsung LCD Screen LTI460WT-L17 | |
|---|---|
| manufacturer | Samsung |
| Model P/N | LTI460WT-L17 |
| Diagonal Size | 46" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1366(RGB)×768, WXGA 34PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 1018.35(W)×572.544(H) mm |
| Bezel Opening | 1024.4(W)×578.6(H) mm |
| Outline Size | 1047.4(W)×600.6(H) ×59.3(D) mm |
| Surface | Antiglare (Haze 41%), Hard coating (3H) |
| Brightness | 700 cd/m² (Typ.) |
| Contrast Ratio | 1200:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Display Mode | S-PVA, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 10/6 (Typ.)(Tr/Td), 8 (Typ.)(G to G) |
| Display Colors | 16.7M 72% NTSC |
| Lamp Type | 24 pcs CCFL , 50K hours , With Inverter |
| Frequency | 60Hz |
| Touch Screen | Without |
| Videowall Seam | 29.0 mm (active to active seam) |
| Application | Digital Signage / Video Wall |
| Signal Interface | LVDS (1 ch, 8-bit) , 30 pins Connector |
| Input Voltage | 5.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| LTI460WT-L17 Original 46.0 inch 1366*768 LCD Screen Display Module for Digital Signage | |
LTI460WT-L17 Please note!
We test all products before sending. But we can't control everything, and the screen is easily damaged during transportation. Therefore, test the product before installation. If you find some problems, please don't install and contact us. If you have not tested the installation, we will not provide after sales service and refund service. We are not responsible for any problems that occur during the installation process.
LTI460WT-L17 Shipping and Package :
LTI460WT-L17 Shipping time:
We try our best to ship out same day for payment cleared before 17.00 PM (Beijing Time) , otherwise we will ship on next working day.Order placed on weekend or holiday will be shipped on Monday or next working day.when we shipped, you can see the tracking number in your order.
LTI460WT-L17 Warranty terms and return policy:
We do not provide warranty for these products
1. Regarding missing / defective parts, please notify us within 7 days after receiving the item, and we will arrange to reship the item.
2. The buyer should exchange it with us by email before returning the item, so that the buyer bears the shipping and handling costs, and the item must also be
3. When returning goods, please put them in the box and packing box.
We will refund the part immediately after receiving the part, the shipping fee is not refundable, and the shipping fee will be paid by the buyer.
Please leave the accessories to professionals.
Our screens have been well tested before shipment.
LTI460WT-L17 FAQ:
Q: How long is the warranty of LTI460WT-L17 ?
A: 90days warranty .
Q: Can I pay my goods LTI460WT-L17 by credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: How do you ship my goods LTI460WT-L17 ?
A: We can shipping all over the world.via DHL,UPS,Fedex and EMS.
Q: Are you manufactory or trade company ?
A: We are a Trade Company , We are LCD panel professional distributors ,We have own warehouse and inventory. Our goal is to provide our customers with the best products.
