LTI460AA01-001 1366*768 Samsung Display Video Wall Monitor Panel
Product Details:
| Place of Origin: | China |
| Brand Name: | Samsung |
| Model Number: | LTI460AA01-001 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | LTI460AA01-001 | Diagonal Size: | 46" |
|---|---|---|---|
| Resolution: | 1366(RGB)×768, WXGA 34PPI | Active Area: | 1018.35(W)×572.544(H) Mm |
| Bezel Opening: | 1024.4(W)×578.6(H) Mm | Outline Dim.: | 1047.4(H)×600.6(V)×59.3(D) Mm |
| Luminance: | 700 Cd/m² (Typ.) | Contrast Ratio: | 2000:1 (Typ.) (TM) |
| Spliced Seam: | 29.0 Mm (active To Active Seam) | Designed For: | Digital Signage / Video Wall |
| High Light: | Samsung Display Video Wall,Samsung LCD Screen Panel,LTI460AA01-001 Display Video Wall |
||
Product Description
LTI460AA01-001 1366*768 Samsung Display Video Wall Monitor Panel
LTI460AA01-001 1366*768 Samsung 46.0 inch monitor lcd Screen panel
LTI460AA01-001 Product details :
| Samsung LCD Screen LTI460AA01-001 | |
|---|---|
| manufacturer | Samsung |
| Model P/N | LTI460AA01-001 |
| Diagonal Size | 46" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1366(RGB)×768, WXGA 34PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 1018.35(W)×572.544(H) mm |
| Bezel Opening | 1024.4(W)×578.6(H) mm |
| Outline Dim. | 1047.4(H)×600.6(V)×59.3(D) mm |
| Treatment | Glare (Haze 0%), Hard coating (3H) |
| Luminance | 700 cd/m² (Typ.) |
| Contrast Ratio | 2000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 10/6 (Typ.)(Tr/Td), 8 (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Operating Mode | S-PVA, Normally Black, Transmissive |
| Support Color | 16.7M 72% NTSC |
| Light Source | CCFL [24 pcs] , 50K hours , With Inverter |
| Spliced Seam | 29.0 mm (active to active seam) |
| Designed For | Digital Signage / Video Wall |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | LVDS (1 ch, 8-bit) , 30 pins Connector |
| Power Supply | 12.0V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| LTI460AA01-001 1366*768 Samsung 46.0 inch monitor lcd Screen panel | |
LTI460AA01-001 NOTE:
We test all products before sending. But we can't control everything, and the screen is easily damaged during transportation. So please test the product before installation. If you find some problems, please do not install and contact us. If you have not tested the installation, we will not provide after-sales service and refund service. We are not responsible for all problems that occur during the installation process.
LTI460AA01-001 Shipping and Package :
LTI460AA01-001 Shipment:
When you place an order, please choose a shipping method and pay for the order including the shipping fee. We will send the items within 3 days once your payment is completed.We do not uarantee delivery time on all international shipments due to differences in customs clearing times in individual countries, which may affect how quickly your product is inspected.
LTI460AA01-001 Contact Us:
· If you have any question, please feel free to contact us. It's our pleasure to serve you!
· We appreciate your business!
LTI460AA01-001 FAQ:
Q: How can I trace my order of LTI460AA01-001 ?
A: we will give you tracking number then you can trace your order from website.
Q: How to make payment of LTI460AA01-001 ?
A: We accept T/T , Paypal , western union .
Q: Can you give me a discount if I need a large quantity of LTI460AA01-001 ?
A: Of course!If you make a large order, we will give you a discount.
Q: Can I pay my order of LTI460AA01-001 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
