40 Inch LTI400HM03 LCD Video Wall Ad Player Panel 1920*1080 Resolution
Product Details:
| Place of Origin: | China |
| Brand Name: | Samsung |
| Model Number: | LTI400HM03 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | LTI400HM03 | Diagonal Size: | 40" |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080, FHD 55PPI | Active Area: | 885.6(W)×498.15(H) Mm |
| Bezel Opening: | 891.7(W)×504.2(H) Mm | Outline Dim.: | 911.7(W)×524.2(H)×61.6(D) Mm |
| Luminance: | 700 Cd/m² (Typ.) | Contrast Ratio: | 3000:1 (Typ.) (TM) |
| Spliced Seam: | 26.1 Mm (active To Active Seam) | Designed For: | Digital Signage / Video Wall |
| High Light: | Ad Player LCD Video Wall,LTI400HM03 LCD Video Wall,LTI400HM03 Lcd Ad Player |
||
Product Description
40 Inch LTI400HM03 LCD Video Wall Ad Player Panel 1920*1080 Resolution
40 inch 1920*1080 Resolution lcd ad player LTI400HM03 LCD panel
LTI400HM03 Product details :
| Samsung LCD Screen LTI400HM03 | |
|---|---|
| manufacturer | Samsung |
| Model P/N | LTI400HM03 |
| Diagonal Size | 40" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1920(RGB)×1080, FHD 55PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 885.6(W)×498.15(H) mm |
| Bezel Opening | 891.7(W)×504.2(H) mm |
| Outline Dim. | 911.7(W)×524.2(H)×61.6(D) mm |
| Treatment | Antiglare (Haze 44%), Hard coating (3H) |
| Luminance | 700 cd/m² (Typ.) |
| Contrast Ratio | 3000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 15/6 (Typ.)(Tr/Td), 8 (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Operating Mode | S-PVA, Normally Black, Transmissive |
| Support Color | 16.7M 72% NTSC |
| Light Source | CCFL [12 pcs] , 50K hours , With Inverter |
| Spliced Seam | 26.1 mm (active to active seam) |
| Designed For | Digital Signage / Video Wall |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | LVDS (2 ch, 8-bit) , 51 pins Connector |
| Power Supply | 12.0V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 65 °C |
| 40 inch 1920*1080 Resolution lcd ad player LTI400HM03 LCD panel | |
LTI400HM03 Useful message:
1. We will ship it with in 48 hours after you finishing the payment.
2. Our goods will ship with the Strong Packing , Antistatic bags +Bubble bag +Carton Box.
3. Before you confirming the screen can work perfectly, please do not use the adhesive to install our screen to your equipment, if the screen paste the glue, we can not accept you to return it and ask for the payment refunding.
4. Please test the LCD Screen before installing, take a video when test it, make sure it work good, then install. If LCD screen can't work, please provide us this video, we will provide you solution.
5.Please power off your device/ pull off the battery before you test or install the LCD screen! Other wise it won't work!
6.LCD screen is fragile, very easy to break, please be careful when you test or install !
LTI400HM03 Shipping and Package :
LTI400HM03 Shipping:
· We ship items to Worldwide!
· Please confirm your address in paypal, phone number is also very important.
· All items will be shipped within 48 working hours on receipt of cleared payment.
· We'll add tracking number after sending the item so that you can track your parcel.
LTI400HM03 About YONGS Electronic Parts:
All of the above LCDs are welcome to order in bulk. The best price and quality products are available upon request. If you are interested, please contact us.
we can help you to find your wanna items in the wholesale Market, and Please send the detailed list to us.
LTI400HM03 FAQ:
Q: Can You declare my order of LTI400HM03 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: How to make payment of LTI400HM03 ?
A: We accept T/T , Paypal , western union .
Q: How long is the warranty ?
A: We offer 90days warranty .
Q: Can I pay my order of LTI400HM03 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
