55.0 inch LCD Screen panel LD550DUN-TGA1 for LCD Video wall
Product Details:
| Place of Origin: | China |
| Brand Name: | LG Display |
| Model Number: | LD550DUN-TGA1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | LD550DUN-TGA1 | Diagonal Size: | 55" |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080, FHD 40PPI | Active Area: | 1209.6(W)×680.4(H) Mm |
| Outline Dim.: | 1213.4(H)×684.2(V)×51.3(D) Mm | Luminance: | 700 Cd/m² (Typ.) |
| Contrast Ratio: | 1400:1 (Typ.) (TM) | Response Time: | 12 (Typ.)(G To G) |
| Spliced Seam: | 3.8 Mm (active To Active Seam) | Designed For: | Video Wall |
Product Description
55.0 inch LCD Screen panel LD550DUN-TGA1 for LCD Video wall
LD550DUN-TGA1 Product details :
| LG Display LCD Screen LD550DUN-TGA1 | |
|---|---|
| manufacturer | LG Display |
| Model P/N | LD550DUN-TGA1 |
| Diagonal Size | 55" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1920(RGB)×1080, FHD 40PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 1209.6(W)×680.4(H) mm |
| Bezel Opening | 1209.9(W)×680.7(H) mm |
| Outline Dim. | 1213.4(H)×684.2(V)×51.3(D) mm |
| Treatment | Hard coating (3H), Reflection 2.0% (Max.) |
| Luminance | 700 cd/m² (Typ.) |
| Contrast Ratio | 1400:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 12 (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) |
| Operating Mode | S-IPS, Normally Black, Transmissive |
| Support Color | 1.06B 99% sRGB |
| Light Source | WLED , 60K hours , With LED Driver |
| Spliced Seam | 3.8 mm (active to active seam) |
| Designed For | Video Wall |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | LVDS (2 ch, 10-bit) , 51 pins Connector |
| Power Supply | 12.0V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| 55.0 inch LCD Screen panel LD550DUN-TGA1 for LCD Video wall | |
LD550DUN-TGA1 NOTE:
We are a professional supplier of industrial control parts. We have a lot of products and only show a small number of products on the website. If you need other products,please contact us.
LD550DUN-TGA1 Shippment & Packing
LD550DUN-TGA1 Delivery details:
We will ship all items within 5 working days upon receipt of payment,our goal is: ship it as fast as we can.
Standard Shipping: To USA,Europe and Australia by SpeedPAK,need 15 working days.
All parcels will provide tracking number for you track.
Expedited/Standard Int'l Shipping by FEDEX : To USA,need 5-6 working days,To other countries,need 6-8 working days normally.But sometimes int'l delivery is highly depended on the courier company and local customs/duties.
Import duties and taxes are not included in the item price or shipping charges.These charges are the buyer responsibility.
LD550DUN-TGA1 Useful news:
1. Our goods will ship with the Strong Packing , Antistatic bags +Bubble bag +Carton Box.
2. Before you confirming the screen can work perfectly, please do not use the adhesive to install our screen to your equipment, if the screen paste the glue, we can not accept you to return it and ask for the payment refunding.
3. Please test the LCD Screen before installing, take a video when test it, make sure it work good, then install. If LCD screen can't work, please provide us this video, we will provide you solution.
4.Please power off your device/ pull off the battery before you test or install the LCD screen! Other wise it won't work!
5.LCD screen is fragile, very easy to break, please be careful when you test or install !
LD550DUN-TGA1 FAQ:
Q: Can I pay my order of LD550DUN-TGA1 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: How long is the warranty ?
A: We offer 90days warranty .
Q: Can You declare my order of LD550DUN-TGA1 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: How to make payment of LD550DUN-TGA1 ?
A: We accept T/T , Paypal , western union .
