42.0 inch TFT LCD Panel Outdoor Digital Signage Screen Replacement
Product Details:
| Place of Origin: | China |
| Brand Name: | LG Display |
| Model Number: | LD420WUB-SCC1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | LD420WUB-SCC1 | Diagonal Size: | 42" |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080, FHD 52PPI | Active Area: | 930.24(W)×523.26(H) Mm |
| Bezel Opening: | 936.2(W)×529.2(H) Mm | Outline Dim.: | 956.4(W)×549.4(H)×54.5(D) Mm |
| Luminance: | 1000 Cd/m² (Typ.) | Contrast Ratio: | 1200:1 (Typ.) (TM) |
| Splicing Seam: | 26.2 Mm (active To Active Seam) | Designed For: | Digital Signage / Video Wall / Outdoor High Brightness |
| High Light: | 42.0 inch TFT LCD Panel,LD420WUB-SCC1 TFT LCD Panel,TFT Digital Signage Screen |
||
Product Description
42.0 inch TFT LCD Panel Outdoor Digital Signage Screen Replacement
42.0 inch TFT Panel Digital Signage Replacement Screen Lcd Monitor LD420WUB-SCC1
LD420WUB-SCC1 Product details :
| LG Display LCD Screen LD420WUB-SCC1 | |
|---|---|
| manufacturer | LG Display |
| Model P/N | LD420WUB-SCC1 |
| Diagonal Size | 42" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1920(RGB)×1080, FHD 52PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 930.24(W)×523.26(H) mm |
| Bezel Opening | 936.2(W)×529.2(H) mm |
| Outline Dim. | 956.4(W)×549.4(H)×54.5(D) mm |
| Treatment | Antiglare (Haze 10%), Hard coating (3H) |
| Luminance | 1000 cd/m² (Typ.) |
| Contrast Ratio | 1200:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 9 (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) |
| Operating Mode | S-IPS, Normally Black, Transmissive |
| Support Color | 16.7M/1.06B 71% NTSC |
| Light Source | CCFL , 50K hours , With Inverter |
| Spliced Seam | 26.2 mm (active to active seam) |
| Designed For | Digital Signage / Video Wall / Outdoor High Brightness |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | LVDS (2 ch, 8/10-bit) , 51 pins Connector |
| Power Supply | 12.0V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| 42.0 inch TFT Panel Digital Signage Replacement Screen Lcd Monitor LD420WUB-SCC1 | |
LD420WUB-SCC1 Features:
1.Highest quality LCD screen replacement parts.
2.Reasonable and competitive price.
3.It is used to repair faulty screen, Touch Screen problems, dead pixels, cracked Touch screens, broken etc.
4.Each assembly is tested before shipping and is 100% working;Quality control: All are tested before delivery,No any Dark Spots,Color Point,Deal Pixels.
LD420WUB-SCC1 Shippment & Packing
LD420WUB-SCC1 Shipping:
· Please note: business/working days(NOT including the weekend or the holidays.)
1.We will ship the item as soon as possible after the payment cleared.The shipping time of the following sometimes maybe a little longer due to custom problems,holidays or something uncertain reasons.
· For faster delivery,please contact us for express details.
2.Please make sure your shipping address is the right one.
3.The package are safe with signature required.If none sign for the package,it will be return.Please don't forget to go to post office to pick it up.
LD420WUB-SCC1 Returns:
· We will accept returns which were shipped as an incorrect item, or DOA.
· Defective products can be changed during the warranty.
· Defective products must be returned within 30 days from the RMA issuing date, we will change another one for you or refund your money back.
· If you buy the wrong products, plese inform us as soon as possible. But if you order has been sent, then all the costs(including original freight, handling charges and the return freight, etc. ) are for your account.
LD420WUB-SCC1 FAQ:
Q: If I place order now,when will you ship the goods of LD420WUB-SCC1 ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: Can I pay my order of LD420WUB-SCC1 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: How long is the warranty ?
A: We offer 90days warranty .
Q: Can You declare my order of LD420WUB-SCC1 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
