HannStar Laptop LCD Screen Display Panel HSD101PWW2-A01 For ASUS TF201
Product Details:
| Place of Origin: | China |
| Brand Name: | HannStar |
| Model Number: | HSD101PWW2-A01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | HSD101PWW2-A01 | Diagonal Size: | 10.1" |
|---|---|---|---|
| Resolution: | 1280(RGB)×800, WXGA 149PPI | Active Area: | 216.96(W)×135.6(H) Mm |
| Outline Size: | 229(W)×151(H)×4.88(D) Mm | Treatment: | Glare (Haze 0%), Hard Coating (3H), Reflection 1.5% (Max.) |
| Luminance: | 650 Cd/m² (Typ.) | Contrast Ratio: | 800 : 1 (Typ.) (TM) |
| Mass: | 145/155g (Typ./Max.) | Used For: | Pad & Tablet |
| High Light: | ASUS TF201 LCD Screen Display Panel,HSD101PWW2-A01 LCD Screen Display Panel,HannStar Laptop LCD Screen |
||
Product Description
HannStar Laptop LCD Screen Display Panel HSD101PWW2-A01 For ASUS TF201
HannStar laptop screen LCD panel HSD101PWW2-A01 for ASUS TF201
HSD101PWW2-A01 Product details :
| HannStar LCD Screen HSD101PWW2-A01 | |
|---|---|
| Brand | HannStar |
| Model P/N | HSD101PWW2-A01 |
| Diagonal Size | 10.1" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1280(RGB)×800, WXGA 149PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 216.96(W)×135.6(H) mm |
| Outline Size | 229(W)×151(H)×4.88(D) mm |
| Treatment | Glare (Haze 0%), Hard coating (3H), Reflection 1.5% (Max.) |
| Luminance | 650 cd/m² (Typ.) |
| Luminance | 800 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 25 (Typ.)(Tr+Td) ms |
| Good View at | Symmetry |
| Work Mode | IPS Pro, Normally Black, Transmissive |
| Color Depth | 16.7M 45% NTSC |
| Backlight | WLED , 10K hours , With LED Driver |
| Mass | 145/155g (Typ./Max.) |
| Used for | Pad & Tablet |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (1 ch, 8-bit) , 30 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| HannStar laptop screen LCD panel HSD101PWW2-A01 for ASUS TF201 | |
HSD101PWW2-A01 Payment and Tax:
1.Paypal is perferred and safety
2.Product being shipped outside of China will incur import duties taxes and charges etc.Those fees are not covered by either price or shipping charges of product,and are responsibility of recipient.
3.The order will be cancelled beyond 7 business days on unpaid station.
HSD101PWW2-A01 Shippment & Packing
HSD101PWW2-A01 Warm Tip:
Because China POST AIR MAIL is safety performance low and long time for delivery.If your package is over 200usd or need it urgently, please don't choose the SG post and China Post. Please contact us if you think the shipping cost is wrong.
1)Every products will be tested before delivery, with special instruments or main boards to ensure working.
2)All the products ,3 months warranty ,strictly tested before shipemt,Please inform us WITHIN 3 DAYS after receiving the parcel if you are dissatisfied with products (Real picture and other evidence must be given),then we will offer replacement /refund if the products are not as described.
3)If the item is your prossession more than 7 days ,it is considered used /second –hand ,we will Only offer replacement service after we get your return item .
HSD101PWW2-A01 Important Tips:
Please testing before fixing and please don’t remove the mark before you have confirm the product has not any problem. Buyer once remove the mark, we don’t offer any warranty.
HSD101PWW2-A01 FAQ:
Q: How long will I receive my goods HSD101PWW2-A01 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: Can You declare my order of HSD101PWW2-A01 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: How to make payment of HSD101PWW2-A01 ?
A: We accept T/T , Paypal , western union .
Q: Can you give me a discount if I need a large quantity of HSD101PWW2-A01 ?
A: Of course!If you make a large order, we will give you a discount.
