10.1 inch B101EW05 V1 LCD Screen Display Panel LVDS 40Pins 1280*800
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | B101EW05 V1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | B101EW05 V1 | Diagonal Size: | 10.1" |
|---|---|---|---|
| Resolution: | 1280(RGB)×800 (WXGA) 149PPI | Active Area: | 216.96(H)×135.6(V) Mm |
| Outline(mm): | 229.46(H)×149.1(V) ×5.56(D) Mm | Viewing Angle: | 85/85/85/85 (Typ.)(CR≥10) |
| Brightness: | 350 Cd/m² (Typ.) | Contrast Ratio: | 1300:1 (Typ.) (TM) |
| Response TimeSeam: | 25 (Typ.)(Tr+Td) Ms | Application: | Pad & Tablet |
| High Light: | B101EW05 V1 LCD Screen Display Panel,LVDS LCD Screen Display Panel,B101EW05 V1 LVDS LCD Display |
||
Product Description
10.1 Inch B101EW05 V1 LCD Screen Display Panel LVDS 40Pins 1280*800
B101EW05 V1 10.1Inch LVDS 40Pins 1280*800 LCD Screens
B101EW05 V1 Product details :
| AUO LCD SCREEN B101EW05 V1 | |
| Manufacturer | AUO |
| Model Name | B101EW05 V1 |
| Screen size | 10.1 inch |
| Screen type | LCM, a-Si TFT-LCD |
| Resolution | 1280(RGB)×800, WXGA, 149PPI |
| Pixel Format | RGB Vertical Stripe |
| Display size | 216.96(H)×135.6(V) mm |
| Outline(mm) | 229.46(H)×149.1(V) ×5.56(D) mm |
| Surface | Hard coating (3H), reflectivity 1.5% (Max.) |
| Brightness | 350 cd/m² (Typ.) |
| Contrast | 1300:1 (Typ.) (TM) |
| Work Mode | MVA, often black display, failure mode |
| Viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| Responding | 25 (Typ.)(Tr+Td) ms |
| Number of | 262K, 45% NTSC |
| Backlight type | WLED, 15K hours, with LED driver |
| Screen weight | 180g (Max.) |
| Apply to | Pad & Tablet |
| Refresh rate | 60Hz |
| Touch function | No touch |
| Signal system | LVDS (1 ch, 6-bit), 40 pins, connector |
| Supply voltage | 3.3V (Typ.) |
| Maximum | Storage temperature: -20 ~ 60 °C Working temperature: 0 ~ 50 °C |
| B101EW05 V1 10.1Inch LVDS 40Pins 1280*800 LCD Screens | |
B101EW05 V1 About Us:
We currently stock over 18,000,000 items with an MSRP greater than $2 billion dollars. YONGSl offers substantial cost savings while receiving quality products. Thank you again for visiting YONGS. For order questions and technical support please contact us via the Whatsapp Message System/Contact Seller.
B101EW05 V1 Package and shippingtime:
We have a professional team of packs that will pack your package more robustly and let it reach you safely, so you do not have to worry about it.
1. epacket:It usual takes 10-20 workdays to get the parcel.
2. EMS:It usual takes 7-10 workdays to get the parcels.
3. DHL:It usual takes 5-7 workdays to get the parcel.
4. China post :It usual takes 15-40 workdays,Brazil will maybe take more days to get the parcel.
B101EW05 V1 Quality & Warranty and customes free:
1. If you have any problems within 1 months after you get your item,you can talk to us,we will try our best to offer you a best solution.
2. If you buy the wrong items or you don't want the item that you bought,you can return it back to us within 3 days,but you should offer the shipping fee.
3. We will be the best price to sell you the product, the price does not include customs fees, if the parcel caused by customs costs, you should pay their own.
4. If you did not receive the package after delivery, please contact us, we will handle your problem.
B101EW05 V1 FAQ:
Q: How long is the warranty of B101EW05 V1 ?
A: 90days warranty .
Q: Can you give me a discount if I need a large quantity of B101EW05 V1 ?
A: Of course!If you make a large order, we will give you a discount.
Q: If I order B101EW05 V1 now,when will you ship the goods ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: Do you accept sample orders for B101EW05 V1 ?
A: Of course!sample order is welcome !
