10.1 Inch 1280*800 Netbook PC LCD Screen Display Panel TFT Module
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | B101EW02 V1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | B101EW02 V1 | Diagonal Size: | 10.1" |
|---|---|---|---|
| Resolution: | 1280(RGB)×800 (WXGA) 149PPI | Display Size: | 222.72(W)×125.28(H) Mm |
| Outline Size: | 235(W)×143.2(H) ×5.2(D) Mm | Brightness: | 200 Cd/m² (Typ.) |
| Contrast Ratio: | 500:1 (Typ.) (TM) | Viewing Angle: | 45/45/15/35 (Typ.) (CR≥10) |
| Display Colors: | 262K , 45% NTSC | Application: | Netbook PC |
| High Light: | Netbook PC LCD Screen Display Panel,TFT Module LCD Screen Display Panel,B101EW02 V1 TFT LCD Module |
||
Product Description
10.1 Inch 1280*800 Netbook PC LCD Screen Display Panel TFT Module
10.1 inch 1280*800 B101EW02 V1 for Netbook PC LCD display TFT Module
B101EW02 V1 Product details :
| Manufacturer | AUO |
| Model Name | B101EW02 V1 |
| Screen size | 10.1 inch |
| Screen type | LCM, a-Si TFT-LCD |
| Resolution | 1280(RGB)×800 (WXGA) 149PPI |
| Pixel | RGB triangle |
| Display size | 222.72 × 125.28 mm (H×V) |
| Outline Size | 235(W)×143(H) ×5.2(D) mm |
| Bezel Opening | 225.73(W)×128.43(H) mm |
| Surface | Mirror (Haze 0%) |
| Brightness | 200 cd/m² (Typ.) |
| Contrast | 500: 1 (Typ.) [Transmission] |
| Best angle | 6 o'clock |
| Optical mode | AHVA, normally black display, transmissive |
| Viewing angle | 45/45/15/35 (Typ.)(CR≥10) |
| Responding | 12/4 (Typ.)(Tr/Td) ms |
| Number of | 262K, 45% NTSC |
| Backlight type | WLED, 12K hours, with LED driver |
| Refresh rate | 60Hz |
| Touch function | No touch |
| Application | Netbook PC |
| Shape Style | Wedge (PCBA Bent, T≥5.2mm) |
| Signal system | 40 pins LVDS (1 ch, 6-bit), connector |
| Supply voltage | 3.3V (Typ.) |
| Maximum | Storage temperature: -20 ~ 60 °C Working temperature: 0 ~ 50 °C |
| 10.1 inch 1280*800 B101EW02 V1 for Netbook PC LCD display TFT Module | |
B101EW02 V1 Contact Us:
1. If there's any problem, please do not hesitate to contact us by message, we will reply you within 1 business day. (Not include public holiday)
2. Working Hours: Monday to Saturday
3. If you don't get response within 1-2 business days, please check your email or My Messages in case your email provider has an overly aggressive spam filter blocking or my emails. Please add us in your contact and email us again.
4. Bulk order is acceptable, lower prices will be offered to you for bulk order.
B101EW02 V1 Deliverytime:
Your package will be shipped within 1-3 busine ss days after the payment is cleared.
B101EW02 V1 Shipping:
1. We will test them strictly before shipment.
2. We will only pay the shipping cost and tax for our country, if there is any shipping cost and tax in your country, you should pay for it.
3. We will send the product within7 working days after receiving the order.(In special cases, we will extend the delivery of products)
4.Many of the original LCD screen has been discontinued, we sell the Used ones of great working condition.Or arrange for alternative products.
5.Please confirm it with us before buying if you need 100% new.
B101EW02 V1 GUARANTEE AND RETURN:
1. We offer guarantee for all our products.
2. Buyers will bear the shipping cost of returning defective or non-defective items.
3. Returned items must be in good condition like the one we send, not damaged.
4. Returned items are subject to approval by us, must be in the original box as shipped.
5. Damaged items received must be reported within 2 days.
6. All non-seller error returns,shipping and handling charges are non-refundable.
B101EW02 V1 FAQ:
Q: When will my order 10.1 inch lcd panel B101EW02 V1 ship?
A: The order are shipped within 1-2 working days after received the payment.
Q: Can you test 10.1 inch lcd panel B101EW02 V1 before shipping?
A: Don't Worry , The B101EW02 V1 was tested ok before shipping.
Q: What happen if B101EW02 V1 I received can't work ?
A: The B101EW02 V1 will be tested ok before shipping .If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel.
B101EW02 V1 Shippment & Packing
