1280x800 149 PPI B101EVT03.1 Touch Screen Display RGB Triangle Pixel
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | B101EVT03.1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | B101EVT03.1 | Diagonal Size: | 10.1" |
|---|---|---|---|
| Resolution: | 1280(RGB)×800 (WXGA) 149PPI | Display Size: | 216.96(W)×135.6(H) Mm |
| Outline Dim: | 253.15(W)×167.75(H) ×6.7(D) Mm | Brightness: | 300 Cd/m² (Typ.) |
| Viewing Angle: | 85/85/85/85 (Typ.) (CR≥10) | Number Of Colors: | 262K , 45% NTSC |
| Contrast Ratio: | 1300:1 (Typ.) (TM) | Designed For: | Pad & Tablet |
| High Light: | B101EVT03.1 Touch Screen Display,PCAP Touch Screen Display,B101EVT03.1 |
||
Product Description
1280x800 149 PPI B101EVT03.1 Touch Screen Display RGB Triangle Pixel
10.1 inch 1280x800 149 PPI B101EVT03.1 Touch Screen Display
B101EVT03.1 Product details :
| AUO LCD SCREEN B101EVT03.1 | |
| Panel Brand | AUO |
| Model Name | B101EVT03.1 |
| Screen size | 10.1 inch |
| Screen type | LCM, a-Si TFT-LCD |
| Resolution | 1280(RGB)×800 (WXGA) 149PPI |
| Pixel | RGB triangle |
| Display size | 216.96 × 135.6 (H×V) mm |
| Outline Size | 253.15(W)×167.75(H) ×6.7(D) mm |
| Surface | Matte |
| Brightness | 300 cd/m² (Typ.) |
| Contrast | 1300: 1 (Typ.) (transmission) |
| Best View on | Symmetry |
| Viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| Responding | 25 (Typ.)(Tr+Td) ms |
| Number of | 262K, 47% NTSC |
| Backlight type | WLED , 15K hours , With LED Driver |
| Screen weight | TBD |
| Refresh rate | 60Hz |
| Application | Pad & Tablet |
| Touch function | PCAP, I²C |
| Signal system | LVDS (1 ch, 6-bit), connector, 40 pins |
| Supply voltage | 3.3V (Typ.) |
| Maximum | Storage temperature: -20 ~ 60 °C Working temperature: 0 ~ 50 °C |
| 10.1 inch 1280x800 149 PPI B101EVT03.1 Touch Screen Display | |
B101EVT03.1 A letter to the buyer:
Dear buyer, if you can't confirm your machine screen, please take the photo off the sending screen, we can confirm your screen through photos, and we are a professional LCD screen supplier, we have a lot of screens. If you want any screen to give us information, due to the time difference, we will respond to the information as soon as we see the information, thank you for watching, the best wishes are given to you. for fast delivery.
B101EVT03.1 Deliverytime:
Your package will be shipped within 1-3 busine ss days after the payment is cleared.
B101EVT03.1 Package and shipping time:
We have professional team packages that will package your package more strongly and let it get to you s afely, so you do not have to worry about it.
1. epacket: It usually takes 10-20 working days to receive the parcel.
2. EMS: It usually takes 7-10 business days to receive the parcel.
3. DHL: It usually takes 5-7 business days to recei ve the parcel.
4. China post: It usually takes 15-40 days, Brazil can take several days to receive the parcel.
B101EVT03.1 Quality and Guarantee and customs for free:
1. If you have problems for 1 month after you rec eive your item, you can talk with us, we will try our best to offer you the best solution.
2.if you buy the wrong items or you do not want t he item that you bought, you can return it back to us within 3 days, but you have to offer the shippin g cost.
3.we will be the best price to sell you the product, the price does not include customs fees, if the parcel caused by customs costs, you have to pay yourself.
4. If you do not receive the package , please contact us, we will work with the problem.
B101EVT03.1 FAQ:
Q: Can I pay my goods B101EVT03.1 by credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: Can you give me a discount if I need a large quantity of B101EVT03.1 ?
A: Of course!If you make a large order, we will give you a discount.
Q: Do you accept sample orders for B101EVT03.1 ?
A: Of course!sample order is welcome !
Q: How to make payment for B101EVT03.1 ?
A: We accept T/T , Paypal , western union .
B101EVT03.1 Shippment & Packing
