12.1 inch LCD Screen Display HSD121MS11-A for Industrial lcd panel
Product Details:
| Place of Origin: | China |
| Brand Name: | HannStar |
| Model Number: | HSD121MS11-A |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | HSD121MS11-A | Diagonal Size: | 12.1" |
|---|---|---|---|
| Resolution: | 800(RGB)×600, SVGA 82PPI | Active Area: | 246(W)×184.5(H) Mm |
| Bezel Opening: | 249.8(W)×188.5(H) Mm | Outline Dim.: | 276.2(H)×209.5(V) Mm |
| Luminance: | 400 Cd/m² (Typ.) | Contrast Ratio: | 350:1 (Typ.) (TM) |
| Weight: | 830g (Typ.) | Designed For: | Industrial |
Product Description
12.1 inch LCD Screen Display HSD121MS11-A for Industrial lcd panel
HSD121MS11-A Product details :
| HannStar LCD Screen HSD121MS11-A | |
|---|---|
| Panel Brand | HannStar |
| Model P/N | HSD121MS11-A |
| Diagonal Size | 12.1" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 800(RGB)×600, SVGA 82PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 246(W)×184.5(H) mm |
| Bezel Opening | 249.8(W)×188.5(H) mm |
| Outline Dim. | 276.2(H)×209.5(V) mm |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 400 cd/m² (Typ.) |
| Contrast Ratio | 350:1 (Typ.) (TM) |
| View Direction | 6 o'clock |
| Response Time | 25 (Typ.)(Tr+Td) |
| Viewing Angle | 60/60/40/60 (Typ.)(CR≥10) |
| Operating Mode | TN, Normally White, Transmissive |
| Support Color | 262K |
| Light Source | CCFL [4 pcs] , 50K hours , W/O Driver |
| Weight | 830g (Typ.) |
| Designed For | Industrial |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | LVDS (1 ch, 6-bit) , 20 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| 12.1 inch LCD Screen Display HSD121MS11-A for Industrial lcd panel | |
HSD121MS11-A Payments:
We accept paypal only.
Buyer is under obligation if (in case) the item is liable to your country's customs duties. We are not responsible for your country's any taxe or customs fee. Our prices do NOT include any customs duty or tax. Please verify it.
HSD121MS11-A Shippment & Packing
HSD121MS11-A Shipping:
Please read this before buying International Shipping may Be Delayed Due to Customs. Customers are Responsible For All Import Charges, Tariffs, Duties, Taxes, and Fees Associated with Import of the product. Shipping Charges does not include any Import Charges, Tariffs, Duties, Taxes, and Fees Associated with it. We are not responsible for undeliverable address.
We reserve the right to charge the shipping fee again for returned items due to wrong address.
Items are generally shipped within 3 business day after your payment has been cleared (Sat. & Sun. excluded.)
HSD121MS11-A Terms of sales:
We test all items before we send them out.
Please check and use the product firstly after it arrives.
If it can't work well or damaged, please contact us directly instead of opening CASE that brings very very bad effect to our store and also takes a very longer time to solve the real problem.
As a seller,we will be responsible for all until the problem is solved.
SO PLEASE CONTACT US DIRECTLY IF ANY PROBLEM HAPPENS.
HSD121MS11-A FAQ:
Q: Can you give me a discount if I need a large quantity of HSD121MS11-A ?
A: Of course!If you make a large order, we will give you a discount.
Q: Can You declare my order of HSD121MS11-A to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: How to make payment of HSD121MS11-A ?
A: We accept T/T , Paypal , western union .
Q: Can I pay my order of HSD121MS11-A via credit card ?
A: Yes!you can use your credit card through your Paypal account.
