New and original 10.1 inch 1024*600 LCD Screen Panel HSD101BFW5-C00 for Automotive Display
Product Details:
| Place of Origin: | China |
| Brand Name: | HannStar |
| Model Number: | HSD101BFW5-C00 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | HSD101BFW5-C00 | Diagonal Size: | 10.1" |
|---|---|---|---|
| Resolution: | 1024(RGB)×600, WSVGA 117PPI | Active Area: | 222.72(W)×125.28(H) Mm |
| Outline Size: | 230.83(W)×135.3(H) Mm | Brightness: | 0 Cd/m² |
| Contrast Ratio: | 500:1 (Typ.) (TM) | Display Mode: | TN, Normally White, Transmissive |
| Display Colors: | 16.7M 45% NTSC | Application: | Automotive Display |
| Highlight: | LCD Screen For Tablet,lcd display panel,tft screen display |
||
Product Description
New and original 10.1 inch 1024*600 LCD Screen Panel HSD101BFW5-C00 for Automotive Display
HSD101BFW5-C00 Product details :
| HannStar LCD Screen HSD101BFW5-C00 | |
|---|---|
| Panel Brand | HannStar |
| Model P/N | HSD101BFW5-C00 |
| Diagonal Size | 10.1" |
| Panel Type | a-Si TFT-LCD, CELL , Q-CUT (Full Cell) |
| Resolution | 1024(RGB)×600, WSVGA 117PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 222.72(W)×125.28(H) mm |
| Outline Size | 230.83(W)×135.3(H) mm |
| Brightness | 0 cd/m² |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| Viewing Angle | 80/80/70/80 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 16 (Typ.)(Tr+Td) |
| Transmissivity | 16% (Typ.)(without Polarizer) |
| Display Colors | 16.7M 45% NTSC |
| Lamp Type | No B/L |
| Touch Screen | Without |
| Application | Automotive Display |
| Driver IC | COG Suggest ILI6150H2-9G + ILI5120-9G |
| Environment | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C |
| New and original 10.1 inch 1024*600 LCD Screen Panel HSD101BFW5-C00 for Automotive Display | |
HSD101BFW5-C00 Payment:
When buying on ALI, your payments are protected by Escrow. Track your order at any stage of delivery online and feel secure that payment will only be released to the supplier after you confirm receipt of your order. With Escrow, your credit card details are never exposed.
HSD101BFW5-C00 Shippment & Packing
HSD101BFW5-C00 Warm Reminder:
To Brazil buyers, Need to offer us CNPJ or CPF if ship the goods by DHL/FEDEX/EMS.
To Russia buyers, The goods only can be shipped by EMS/ePacket, The buyer need to offer full name of receiver!
The Duty or custom fees is depend on BUYER country, Not Seller! If need declare low value when shipping , Please advise us in time !
To remote areas buyers , If ship the order by FEDEX/DHL , Need to add extra fee USD30.00, Hope buyer can understand us.
HSD101BFW5-C00 Return:
If you receive a damaged or wrong item , please contact us via message , we will arrange return immediately. Please do not leave negative feedback or open any cases before contacting us.
Return is accepted within 30 days after receiving of the item.
When doing the return , please pack the product safely like how we do in the original package. As the screens are very fragile.Please do not use other package.
Buyer is responsible for the return shipping cost in the cases of buyer purchasing wrong products , wrong size ,etc..
HSD101BFW5-C00 FAQ:
Q: How can I trace my order of HSD101BFW5-C00 ?
A: we will give you tracking number then you can trace your order from website.
Q: How long is the warranty ?
A: We offer 90days warranty .
Q: Can you give me a discount if I need a large quantity of HSD101BFW5-C00 ?
A: Of course!If you make a large order, we will give you a discount.
Q: Can I pay my order of HSD101BFW5-C00 via credit card ?
A: Yes!you can use your credit card through your Paypal account
