AA084XD11 8.4 Inch Industrial LCD SCREEN Display Panel Replacement Maintenance
Product Details:
| Place of Origin: | China |
| Brand Name: | Mitsubishi |
| Model Number: | AA084XD11 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | AA084XD11 | Diagonal Size: | 8.4" |
|---|---|---|---|
| Resolution: | 1024(RGB)×768, XGA 152PPI | Active Area: | 170.496(W)×127.872(H) Mm |
| Bezel Opening: | 174.9(W)×132.2(H) Mm | Outline Dim.: | 199.5(H)×149(V) ×10.2(D) Mm |
| Treatment: | Antiglare, Hard Coating (3H) | Weight: | 340g (Typ.) |
| Designed For: | Industrial / Outdoor High Brightness | ||
| High Light: | 8.4" Industrial LCD SCREEN Display Panel,AA084XD11 LCD SCREEN Display Panel,152 PPI LCD SCREEN Display Panel |
||
Product Description
AA084XD11 8.4 inch Industrial LCD SCREEN display panel Replacement maintenance
AA084XD11 Product details :
| Mitsubishi LCD SCREEN AA084XD11 | |
|---|---|
| manufacturer | Mitsubishi |
| Model Name | AA084XD11 |
| screen size | 8.4 inch |
| Screen type | a-Si TFT-LCD , LCM |
| Resolution | 1024(RGB)×768, XGA, 152PPI |
| Pixel configuration | RGB Vertical Stripe |
| Display size | 170.496(W)×127.872(H) mm |
| physical dimension | 199.5(W)×149(H) ×10.2(D) mm |
| Visual size | 174.9(W)×132.2(H) mm |
| surface treatment | Antiglare, Hard coating (3H) |
| Brightness | 1000 cd/m² (Typ.) |
| Contrast | 1000:1 (Typ.) (TM) |
| Best angle | Symmetry |
| Optical mode | SWV, Normally Black, Transmissive |
| Viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| Responding time | 12/12 (Typ.)(Tr/Td) |
| Number of color | 262K/16.7M 50% NTSC |
| Backlight type | 2 strings WLED , 100K hours , Without Driver |
| Panel weight | 340g (Typ.) |
| Apply to | Industrial / Outdoor High Brightness |
| Refresh rate | 60Hz |
| Touch function | No touch |
| signal system | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Supply voltage | 3.3V (Typ.) |
| Maximum rating | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C |
| AA084XD11 8.4 inch Industrial LCD SCREEN display panel Replacement maintenance | |
AA084XD11 Payment:
We accept Payment via Bank transefer, EscroW, Western Union and etc, you can contact us if you have any question.
VERIFY: Our prices do NOT include any customs duty or tax.
AA084XD11 Shippment & Packing:
AA084XD11 Shipping :
1, Shipping via China Post Registered Air Mail or ePacket.
2, We will send out your goods within 3 working days after we get your order .
3, Normally , you can get the goods within 27 calendar days .
4, Please make sure your shipping information ( including address / post code / phone number / contact person ) are correct before order . If you want us send it to another address , pls inform us in advance , and leave message in our transaction.
AA084XD11 Reminder :
Our price is not including any customs tax / fee in the destination . You need to pay some tax / fee or not , when the goods get Clearance Customs in the destination Customs , It depends the laws in the destination country .
There are many other high quality products in our store, we sincerely invite you add our store to your store list.
If you have any needs, pls don't hesitate to contact us, we will try our best to help you, hope you can have a happy shopping with us. Best regards!
AA084XD11 FAQ:
Q: Can I pay my order of AA084XD11 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: Can you give me a discount if I need a large quantity of AA084XD11 ?
A: Of course!If you make a large order, we will give you a discount.
Q: How can I trace my order of AA084XD11 ?
A: we will give you tracking number then you can trace your order from website.
Q: How long is the warranty ?
A: We offer 90days warranty .
