AA084VF01 Original 8.4 Inch 640*480 LCD Screen Display For Industrial Equipment
Product Details:
| Place of Origin: | China |
| Brand Name: | Mitsubishi |
| Model Number: | AA084VF01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | AA084VF01 | Diagonal Size: | 8.4" |
|---|---|---|---|
| Resolution: | 640(RGB)×480, VGA 95PPI | Active Area: | 170.88(W)×128.16(H) Mm |
| Bezel Opening: | 174.9(W)×132.2(H) Mm | Outline Dim.: | 199.5(H)×149(V) ×12(D) Mm |
| Luminance: | 480 Cd/m² (Typ.) | Contrast Ratio: | 450:1 (Typ.) (TM) |
| Weight: | 350g (Typ.) | Designed For: | Industrial |
| High Light: | 640*480 LCD Screen Display Panel,AA084VF01 LCD Screen Display Panel,LCD Screen Display Panel 8.4 inch |
||
Product Description
AA084VF01 Original 8.4 inch 640*480 LCD Screen Display for Industrial Equipment
AA084VF01 Product details :
| Mitsubishi LCD SCREEN AA084VF01 | |
|---|---|
| Manufacturer | Mitsubishi |
| Model Name | AA084VF01 |
| Screen Size | 8.4 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 640(RGB)×480 (VGA) 95PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 170.88 × 128.16 (H×V) |
| Outline(mm) | 199.5 × 149 × 12 (H×V×D) |
| Bezel Area(mm) | 174.9 × 132.2 (H×V) |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 480 cd/m² (Typ.) |
| Contrast Ratio | 600 : 1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/60 (Typ.)(CR≥10) |
| Response | 4/12 (Typ.)(Tr/Td) ms |
| Good View at | 6 o'clock |
| Work Mode | TN, Normally White, Transmissive |
| Color Depth | 262K 40% NTSC |
| Backlight | 2 pcs CCFL , 50K hours , No Driver |
| Mass | 350g (Typ.) |
| Used for | Industrial |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | CMOS (1 ch, 6-bit) , 31 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C |
| AA084VF01 Original 8.4 inch 640*480 LCD Screen Display for Industrial Equipment | |
AA084VF01 Payment:
T / T (wire transfer) / Western Union / Paypal, Escrow, Alibaba Trade Security.
1.DHL/EMS/UPS/FEDEX/TNT, etc.
2. The buyer is responsible for any taxes or duties collected by his country.
AA084VF01 Shippment & Packing
AA084VF01 Shipment:
1. We ship to worldwide, per order have a tracking number.
2. Item will be shipped within 2 business days after we received a verified payment.
3. SERVICE TRANSIT TIME is provided by the carrier and excludes weekends and holidays. Transit times may vary,particularly during the holiday season, such as Christmas season and weeks before Chinese New Year Holiday, most warehouses will be full that it will cause delayed to deliver.
4.If you have not received your items within 30 days after payment for postage delivery (like china post), please let us know. We will further track the parcel and reply you ASAP Our goal is customer satisfaction,
5. We support most shipping ways: DHL. UPS, FEDEX,EMS,HK Post,SG Post, China Post etc.
AA084VF01 Warning:
Before ordering, please check and confirm if the screen size, resolution, backlight type, interface type, and location can be applied to your machine. If you are not sure, please ask us for free.
Please provide us with your correct contact information so that you can receive the item as soon as possible.
AA084VF01 FAQ:
Q: When will my order 8.4 inch lcd panel AA084VF01 ship?
A: The order are shipped within 1-2 working days after received the payment.
Q: Can you test 8.4 inch lcd panel AA084VF01 before shipping?
A: Don't Worry , The AA084VF01 was tested ok before shipping.
Q: What happen if LAA084VF01 I received can't work ?
A: The AA084VF01 will be tested ok before shipping .If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel.
