TFT LCD Panel Screen Display Assembly HannStar Monitors 10.3 Inch HSD103JPW2-F10 1920x720
Product Details:
| Place of Origin: | China |
| Brand Name: | HannStar |
| Model Number: | HSD103JPW2-F10 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | HSD103JPW2-F10 | Diagonal Size: | 10.3" |
|---|---|---|---|
| Resolution: | 1920(RGB)×720 200PPI | Active Area: | 243.648(W)×91.368(H) Mm |
| Outline Dim.: | 259.8(H)×111.1(V)×15.3(D) Mm | Luminance: | 1000 Cd/m² (Typ.) |
| Contrast Ratio: | 1500:1 (Typ.) (TM) | Response Time: | 35 (Max.)(Tr+Td) |
| Weight: | 330g (Typ.) | Designed For: | Industrial / Outdoor High Brightness / Automotive Display |
| High Light: | TFT LCD Panel Screen Display Assembly,HSD103JPW2-F10 LCD Panel Screen Display,1920x720 LCD Panel Screen Display |
||
Product Description
HannStar Lcd Monitors 10.3 inch HSD103JPW2-F10 1920x720 TFT LCD Panel Screen Display Assembly Replacement
HSD103JPW2-F10 Product details :
| HannStar LCD Screen HSD103JPW2-F10 | |
|---|---|
| Panel Brand | HannStar |
| Model P/N | HSD103JPW2-F10 |
| Diagonal Size | 10.3" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1920(RGB)×720 200PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 243.648(W)×91.368(H) mm |
| Outline Dim. | 259.8(H)×111.1(V)×15.3(D) mm |
| Treatment | Hard coating |
| Luminance | 1000 cd/m² (Typ.) |
| Contrast Ratio | 1500:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 35 (Max.)(Tr+Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Operating Mode | IPS Pro, Normally Black, Transmissive |
| Support Color | 16.7M 75% NTSC |
| Light Source | WLED [9S4P] , 30K hours , W/O Driver |
| Weight | 330g (Typ.) |
| Designed For | Industrial / Outdoor High Brightness / Automotive Display |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | LVDS (2 ch, 8-bit) , 50 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| HannStar Lcd Monitors 10.3 inch HSD103JPW2-F10 1920x720 TFT LCD Panel Screen Display Assembly Replacement | |
