AA050ME01--T1 Original 5.0 Inch LCD Screen Display For Industrial Equipment
Product Details:
| Place of Origin: | China |
| Brand Name: | Mitsubishi |
| Model Number: | AA050ME01--T1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | AA050ME01--T1 | Diagonal Size: | 5.0" |
|---|---|---|---|
| Resolution: | 800(RGB)×480, WVGA 188PPI | Active Area: | 108(W)×64.8(H) Mm |
| Bezel Opening: | 110.0(W)×66.8(H) Mm | Outline(mm): | 118.5 × 77.8 × 6.5 (H×V×D) |
| Luminance: | 350 Cd/m² (Typ.) | Touchscreen: | 4-wire Resistive Touch |
| Mass: | 89.0g (Typ.) | Used For: | Industrial |
| High Light: | AA050ME01--T1 LCD Display Screen Panel,LCD Touch Panel Display 5.0inch,350cd/m² LCD Touch Panel Display |
||
Product Description
AA050ME01--T1 Original 5.0 inch LCD Screen Display for Industrial Equipment
AA050ME01--T1 Product details :
| Mitsubishi LCD SCREEN AA050ME01--T1 | |
|---|---|
| Manufacturer | Mitsubishi |
| Model Name | AA050ME01--T1 |
| Screen Size | 5.0 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 800(RGB)×480 (WVGA) 188PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 108 × 64.8 (H×V) |
| Outline(mm) | 118.5 × 77.8 × 6.5 (H×V×D) |
| Bezel Area(mm) | 110.0 × 66.8 (H×V) |
| Treatment | Clear, Hard coating (3H) |
| Luminance | 350 cd/m² (Typ.) |
| Contrast Ratio | 450 : 1 (Typ.) (TM) |
| Viewing Angle | 65/65/65/45 (Typ.)(CR≥10) |
| Response | 5/20 (Typ.)(Tr/Td) ms |
| Good View at | 12 o'clock |
| Work Mode | TN, Normally White, Transmissive |
| Color Depth | 16.7M 50% NTSC |
| Backlight | 2 strings WLED , No Driver |
| Mass | 89.0g (Typ.) |
| Used for | Industrial |
| Refresh Rate | 60Hz |
| Touchscreen | 4-wire Resistive Touch |
| Signal Type | CMOS (1 ch, 8-bit) , FPC 45 pins |
| Voltage Supply | 3.3/5.0V (Typ.)(VCC/AVDD) |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| AA050ME01--T1 Original 5.0 inch LCD Screen Display for Industrial Equipment | |
AA050ME01--T1 Payment and Tax:
1.Alipay is perferred and safety
2.Product being shipped outside of China will incur import duties taxes and charges etc.Those fees are not covered by either price or shipping charges of product,and are responsibility of recipient.
AA050ME01--T1 Shippment & Packing:
AA050ME01--T1 Abount Shipping Information:
We will ship out your items within 1-5 business days after the payment is cleared.
Standard shipping using international Airmail,Items ship from China and it takes 7-14 working days (2-3 weeks) to receive for most areas.
If you do not receive item within 30 working days (5 weeks), please contact us to investigate the case.(Brazil. Italy. 5~8 weeks)
AA050ME01--T1 Notes:
1.When ordering our screens, please confirm the model of your tablet.". To avoid purchasing incorrectly and not being able to use properly.
2.Before you confirm that the screen cannot work perfectly, please do not use adhesive to install our screen onto your device. If the screen has adhesive attached, we cannot accept your return and request a refund.
3. Problems you may encounter
A. Broken screen → Making unpacking video → Contact us and send video
B. Non working screen → Create test video → Contact us and send video
4.If everything on our screen is normal, please leave us a positive feedback of five stars, and we will also provide you with good feedback.".
5.If there are any issues with the screen, please contact us immediately and we will handle them for you soon. Please do not leave us any negative feedback or cause disputes at will. Thank you for your understanding. Looking forward to long-term cooperation with you! Happy shopping
AA050ME01--T1 FAQ:
Q: Do you accept the AA050ME01--T1 sample order?
A: Yes , sample order is welcome.
Q: How to order if I don’t know the lcd panel number ?
A: You can offer 2-3 photos (back-side and front-side) for your lcd panel ,So that we can check the panel to you.
Q: What does "We may ship a 100% compatible part number for your screen" mean ?
A: Because some original screens are not available in the market , So we send the compatible item to you .Don't worry , it is 100% compatible for your screen.
Q: How long is the warranty of Mitsubishi AA050ME01--T1 ?
A: NEW Product warranty is 90 days , the secondhand goods is 60days.
