Innolux N140HCA-EBA Laptop LCD Screen Display FHD 1920*1080 Assembly For ASUS VivoBook Flip
Product Details:
| Place of Origin: | China |
| Brand Name: | Innolux |
| Model Number: | N140HCA-EBA |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | N140HCA-EBA | Diagonal Size: | 14.0" |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080, FHD 157PPI | Active Area: | 309.31(W)×173.99(H) Mm |
| Outline(mm): | 315.35 × 197.22 × 3 (H×V×D) | Treatment: | Glare (Haze 0%), Hard Coating (3H) |
| Response: | 14/11 (Typ.)(Tr/Td) Ms | Work Mode: | AAS, Normally Black, Transmissive |
| Outline Shape: | Slim (PCBA Flat, T≤3.2mm) | Used For: | Laptop |
| High Light: | EDP 30 Pins LCD Laptop Screen,N140HCA-EBA Laptop LCD Screen Display,TP412 Laptop LCD Screen Display |
||
Product Description
Innolux N140HCA-EBA 14.0 inch FHD 1920*1080 Laptop LCD Screen Display Assembly For ASUS VivoBook Flip 14 TP412
N140HCA-EBA Product details :
| Innolux LCD SCREEN N140HCA-EBA | |
|---|---|
| Manufacturer | Innolux |
| Model Name | N140HCA-EBA |
| Screen Size | 14.0 inch |
| Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 1920(RGB)×1080 (FHD) 157PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 309.31 × 173.99 (H×V) |
| Outline(mm) | 315.35 × 197.22 × 3 (H×V×D) |
| Treatment | Glare (Haze 0%), Hard coating (3H) |
| Luminance | 220 cd/m² (Typ.) |
| Contrast Ratio | 800 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 14/11 (Typ.)(Tr/Td) ms |
| Good View at | Symmetry |
| Work Mode | AAS, Normally Black, Transmissive |
| Color Depth | 262K 45% NTSC |
| Backlight | WLED , 15K hours , With LED Driver |
| Outline Shape | Slim (PCBA Bent, T≤3.2mm) |
| Used for | Laptop |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | eDP (1 Lane) , eDP1.2 , 30 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| Innolux N140HCA-EBA 14.0 inch FHD 1920*1080 Laptop LCD Screen Display Assembly For ASUS VivoBook Flip 14 TP412 | |
N140HCA-EBA Advantages about us:
1. The LCD screens you buy are all 100% original authentic.
2. Our goods inventory is very sufficient and shipped within 24 hours.
3. Purchase on the same day, there will be a small gift!
4. The customer installs independently and provides installation instructions.
5. Our packaging is professionally customized and very safe! Each package will have a fragile label
6. Product grade provides A grade (perfect) and B grade (defective, imperfect) Meet various customer needs
7. We provide professional after-sales service, serve customers 24 hours a day, and provide a 90-day warranty (calculated from the time the goods arrive at the destination)
N140HCA-EBA Attention:
To avoid wrong order placed or wrong item you bought, here is something you need to read before ordering,
1. Please check your laptop model in compatible list or tell if wide screen or standard screen.
2. Please check the LCD screen size and resolution.
3. Please check the Data connector (14pin, 20pin, 30pin(S M L) ,40pin(S,M,L), 50pin 60pin ) and position
4. Please check the physical resolution pixels of LCD screen.
N140HCA-EBA Shippment & Packing:
N140HCA-EBA Shipping:
(Please note:business/working days:NOT including the weekend nor the holidays.)
1.We will ship the item via Registered Airmail in 2 business days after the payment cleared.The shipping time of the following sometimes maybe a little longer due to custom problems,holidays or something uncertain reasons.
To most of the countries: 25-45 business days (such as Germany, Spain, Swden, Switzerland etc.)
To the USA, UK and Australia: 7-18 business days
To Russia: 25-60 business days due to Russia post is very slow
For faster delivery,please contact us for express details.
2.We ship your parcel worldwide as gift.Please make sure your shipping address is the right one.
3.The package are safe with signature required.If none sign for the package,it will be return.Please don't forget to go to post office to pick it up.Thanks.
N140HCA-EBA FAQ:
Q: Can I pay my order of N140HCA-EBA via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: Can You declare my order of N140HCA-EBA to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: Can you give me a discount if I need a large quantity of N140HCA-EBA ?
A: Of course!If you make a large order, we will give you a discount.
Q: How long is the warranty ?
A: We offer 90days warranty .
