14.0 Inch Laptop LCD Panel Touch Screen N140HCA-EAC Rev.B1 Assembly For Asus VivoBook TM420U TM420I
Product Details:
| Place of Origin: | China |
| Brand Name: | Innolux |
| Model Number: | N140HCA-EAC Rev.B1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | N140HCA-EAC Rev.B1 | Diagonal Size: | 14.0" |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080, FHD 157PPI | Active Area: | 309.31(W)×173.99(H) Mm |
| Outline Size: | 315.81(W)×197.48(H) ×3(D) Mm | Brightness: | 250 Cd/m² (Typ.) |
| Contrast Ratio: | 700:1 (Typ.) (TM) | Display Mode: | AAS, Normally Black, Transmissive |
| Shape Style: | Slim (PCBA Flat, T≤3.2mm) | Application: | Laptop |
| High Light: | Rev.B1 LCD Screen Display Panel,N140HCA-EAC Laptop LCD Panel Touch Screen,TM420I Laptop LCD Panel Touch Screen |
||
Product Description
14.0 Inch Laptop LCD Panel Touch Screen N140HCA-EAC Rev.B1 Assembly For Asus VivoBook TM420U TM420I TM420IA-EC069T
N140HCA-EAC Product details :
| Innolux LCD SCREEN N140HCA-EAC Rev.B1 | |
|---|---|
| Manufacturer | Innolux |
| Model Name | N140HCA-EAC Rev.B1 |
| Screen Size | 14.0 inch |
| Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 1920(RGB)×1080 (FHD) 157PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 309.31 × 173.99 (H×V) |
| Outline Dim. | 315.81(H)×197.48(V) ×3(D) mm |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 250 cd/m² (Typ.) |
| Contrast Ratio | 700:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 14/11 (Typ.)(Tr/Td) ms |
| Good View at | Symmetry |
| Work Mode | AAS, Normally Black, Transmissive |
| Color Depth | 262K 45% NTSC |
| Backlight | WLED , 15K hours , With LED Driver |
| Outline Shape | Slim (PCBA Bent, T≤3.2mm) |
| Used for | Laptop |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | eDP (2 Lanes) , eDP1.2 , 30 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| 14.0 Inch Laptop LCD Panel Touch Screen N140HCA-EAC Rev.B1 Assembly For Asus VivoBook TM420U TM420I TM420IA-EC069T | |
N140HCA-EAC About Product:
1: Please read the product information carefully to avoid buying the wrong product. If you are not sure if the product is right for you, please feel free to contact us. We have professional engineers to help you. We will ask you for pictures and some product information, please reply in time, this is very important.
2: Some products, due to different production time, different production plants, different sales areas. Some coding and details may have some differences. Please don't worry, this is a normal phenomenon. We guarantee that the products are the same.
N140HCA-EAC Shippment & Packing:
N140HCA-EAC Shipping:
(Please note:business/working days:NOT including the weekend nor the holidays.)
1.We will ship the item as soon as possible after the payment cleared.The shipping time of the following sometimes maybe a little longer due to custom problems,holidays or something uncertain reasons.
For faster delivery,please contact us for express details.
2.Please make sure your shipping address is the right one.
3.The package are safe with signature required.If none sign for the package,it will be return.Please don't forget to go to post office to pick it up.
N140HCA-EAC About Warranty:
1: The product is damaged during the warranty period, we can replace it for you for free or a full refund. For some high value products, the buyer needs to return the package to us.
2: Please don't open the dispute at will, give us a negative feedback. Otherwise, you will lose your warranty. If there are any problems with the products, we will try our best to solve the problems and provide good after-sales service. Please keep in touch with us.
N140HCA-EAC FAQ:
Q: Can I pay my order of N140HCA-EAC via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: Can you give me a discount if I need a large quantity of N140HCA-EAC ?
A: Of course!If you make a large order, we will give you a discount.
Q: How can I trace my order of N140HCA-EAC ?
A: we will give you tracking number then you can trace your order from website.
Q: Do you accept sample orders of N140HCA-EAC ?
A: Of course!sample order is welcome !
