BOE Laptop Display 13.3 Inch 30 Pins NV133FHM-N56 FHD IPS LCD Screen Assembly For Xiaomi MI Air 13
Product Details:
| Place of Origin: | China |
| Brand Name: | BOE |
| Model Number: | NV133FHM-N56 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | NV133FHM-N56 | Diagonal Size: | 13.3" |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080, FHD 166PPI | Active Area: | 293.76(W)×165.24(H) Mm |
| Outline Size: | 299.96(W)×186.92(H) ×2.1(D) Mm | Surface: | Antiglare |
| Display Mode: | ADS, Normally Black, Transmissive | Display Colors: | 262K 100% SRGB |
| Shape Style: | Slim (PCBA Flat, T≤3.2mm) | Application: | Laptop |
| High Light: | Laptop LCD Panel,Laptop Screen Monitor,Laptop LCD Display |
||
Product Description
BOE Laptop Display 13.3 Inch 30 Pins NV133FHM-N56 FHD IPS LCD Screen Assembly For Xiaomi MI Air 13
NV133FHM-N56 Product details :
| BOE LCD SCREEN NV133FHM-N56 | |
|---|---|
| Manufacturer | BOE |
| Model Name | NV133FHM-N56 |
| Screen Size | 13.3 inch |
| Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 1920(RGB)×1080 (FHD) 166PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 293.76 × 165.24 (H×V) |
| Outline(mm) | 299.96 × 186.92 × 2.1 (H×V×D) |
| Treatment | Antiglare |
| Luminance | 300 cd/m² (Typ.) |
| Contrast Ratio | 800 : 1 (Min.) (TM) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Response | 30 (Typ.)(G to G) ms |
| Good View at | Symmetry |
| Work Mode | ADS, Normally Black, Transmissive |
| Color Depth | 262K 100% sRGB |
| Backlight | 10S4P WLED , 15K hours , With LED Driver |
| Outline Shape | Slim (PCBA Flat, T≤3.2mm) |
| Used for | Laptop |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | eDP (2 Lanes) , 30 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| BOE Laptop Display 13.3 Inch 30 Pins NV133FHM-N56 FHD IPS LCD Screen Assembly For Xiaomi MI Air 13 | |
NV133FHM-N56 NOTE:
Please take off the screen or cable ,cover ,check the part number before purchase.such as :
a,Tell me LCD model NV133FHM-N56.
b,Tell us your laptop name , such as : YOGA700-14 X1 YOGA, if you don't have the LCD model.
c.Please check the LCD screen size and resolution.
d.Please check the signal connectors (14pin, 20pin, 30pin (S M L) ,40pin (S,M,L ,) 50pin 60pin and position.
Images show actual product, please verify all connectors and specifications carefully.
We will send the compatible one instead if original one out of stock.
NV133FHM-N56 Shippment & Packing
NV133FHM-N56 Shipping Detail:
1: Please confirm your ADDRESS carefully once you make the order.We will send the products to you at once after the payment is received.
2: Items are shipped from China using airmail;reach most of the coun- tries within 15-30 business days.
3: Please contact us if you don't receive the products in 45 days. And please give us 3 working days for checking the undelivered package andthe reason. If it is our problem,we will refund the money to you.
NV133FHM-N56 Policy:
All products are guaranteed for half a year. Artificial damage is not covered by the warranty. All products have special warranty labels. Please do not damage the labels. Without warranty labels, no warranty can be provided.
If you receive a damaged or wrong item , please contact us via message , we will arrange return immediately. Please do not leave negative feedback or open any cases before contacting us.
Return is accepted within 30 days after receiving of the item.
When doing the return , please pack the product safely like how we do in the original package. As the screens are very fragile.Please do not use other package.
Buyer is responsible for the return shipping cost in the cases of buyer purchasing wrong products , wrong size ,etc..
NV133FHM-N56 FAQ:
Q: How can I trace my order of NV133FHM-N56 ?
A: we will give you tracking number then you can trace your order from website.
Q: Do you accept sample orders of NV133FHM-N56?
A: Of course!sample order is welcome !
Q: Can you give me a discount if I need a large quantity of NV133FHM-N56 ?
A: Of course!If you make a large order, we will give you a discount.
Q: Can I pay my order of NV133FHM-N56 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
