AUO 11.6 inch B116XTB01.0 HW1A 1366*768 LCD Screen Panel for Laptop
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | B116XTB01.0 HW1A |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | B116XTB01.0 HW1A | Diagonal Size: | 11.6" |
|---|---|---|---|
| Resolution: | 1366(RGB)×768, WXGA 135PPI | Active Area: | 256.125(W)×144(H) Mm |
| Outline Size: | 284.1(W)×185(H) ×4.2(D) Mm | Brightness: | 200 Cd/m² (Typ.) |
| Contrast Ratio: | 500:1 (Typ.) (TM) | Best View On: | 6 O'clock |
| Response Time: | 8 (Typ.)(Tr+Td) | Application: | Laptop |
Product Description
AUO 11.6 inch B116XTB01.0 HW1A 1366*768 LCD Screen Panel for Laptop
B116XTB01.0 HW1A Product details :
| Brand | AUO |
| Model P/N | B116XTB01.0 HW1A |
| Diagonal Size | 11.6" |
| Panel Type | a-Si TFT-LCD, Assembly |
| Resolution | 1366(RGB)×768, WXGA 135PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 256.125(W)×144(H) mm |
| Bezel Opening | 257.7(W)×145.6(H) mm |
| Outline Dim. | 284.1(W)×185(H) ×4.2(D) mm |
| Treatment | Glare (Haze 0%), Hard coating (3H) |
| Luminance | 200 cd/m² (Typ.) |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| View Direction | 6 o'clock |
| Response Time | 8 (Typ.)(Tr+Td) |
| Viewing Angle | 45/45/15/35 (Typ.)(CR≥10) |
| Operating Mode | - |
| Support Color | 262K 45% NTSC |
| Light Source | WLED , 15K hours , With LED Driver |
| Shape Style | - |
| Designed For | Laptop |
| Frame Rate | 60Hz |
| Touch Panel | On-Cell Touch, USB |
| Interface Type | eDP (1 Lane) , eDP1.2 , 40 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temp.: -20 ~ 60 °C ; Storage Temp.: -20 ~ 60 °C |
B116XTB01.0 HW1A Description:
1.Highest quality touch LCD screen replacement parts.
2.Reasonable and competitive price.
3.It is used to repair faulty screen, Touch Screen problems, dead pixels, cracked Touch screens, broken etc.
4.Each assembly is tested beforeshipping and is 100% working;Quality control: All are tested beforedelivery,No any Dark Spots,Color Point,Deal Pixels.
5.if you have any problem with the item, please contact me before you buy it, we will reply to you as soon as possible.
6.Each item has been checked and in good condition before shipping.
7. It is shipped in protective bubble wrap and has all the protective screen coatings, so, please do not worry.
B116XTB01.0 HW1A Shippment & Packing
B116XTB01.0 HW1A Abount Shipping Information:
We will ship out your items within 1-5 business days after the payment is cleared.
Standard shipping using international Airmail,Items ship from China and it takes 7-14 working days (2-3 weeks) to receive for most areas.
If you do not receive item within 30 working days (5 weeks), please contact us to investigate the case.(Brazil. Italy. 5~8 weeks)
B116XTB01.0 HW1A Contact us:
All the items are original & authentic. Each one will be tested strictly before shipment.
Office Hours:9:00am-18:30pm,
Monday-Saturday, Beijing Time.(Except oficial holidays.)
Please help yourself to order if we're offline.
We'll reply as soon as we get to work and arrange delivery quickly.
For large amount,please do not hesitate to contact us for our best price.
You are always welcome to leave us messages.
Expect to have nice co-operation with you.
B116XTB01.0 HW1A FAQ:
Q: Can You declare my order of B116XTB01.0 HW1A to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: How can I trace my order of B116XTB01.0 HW1A ?
A: we will give you tracking number then you can trace your order from website.
Q: How long will I receive my goods B116XTB01.0 HW1A ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: How to make payment of B116XTB01.0 HW1A ?
A: We accept T/T , Paypal , western union .
