DV185WHM NM2 HD BOE Digital Signage And Displays High Brightness 500Nit
Product Details:
| Place of Origin: | China |
| Brand Name: | BOE |
| Model Number: | DV185WHM-NM2 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | DV185WHM-NM2 | Diagonal Size: | 18.5" |
|---|---|---|---|
| Resolution: | 1366(RGB)×768, WXGA 84PPI | Active Area: | 409.8(W)×230.4(H) Mm |
| Bezel Opening: | 413.4(W)×234.0(H) Mm | Outline Size: | 430.4(W)×254.6(H) ×11.4(D) Mm |
| Brightness: | 500 Cd/m² (Typ.) | Contrast Ratio: | 1000:1 (Typ.) (TM) |
| Panel Weight: | 1.30Kgs (Typ.) | Application: | Digital Signage |
| High Light: | HD BOE Digital Signage And Displays,500Nit Digital Signage And Displays,DV185WHM NM2 Lcd Screen Panel |
||
Product Description
DV185WHM NM2 HD BOE Digital Signage And Displays High Brightness 500Nit
DV185WHM-NM2 high brightness 500 nit 1366*768 HD BOE lcd Screen panel for Digital Signage
DV185WHM-NM2 Product details :
| BOE LCD SCREEN DV185WHM-NM2 | |
|---|---|
| Panel Brand | BOE |
| Panel Model | DV185WHM-NM2 |
| Panel Size | 18.5" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1366(RGB)×768, WXGA, 84PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 409.8(W)×230.4(H) mm |
| Bezel Opening | 413.4(W)×234.0(H) mm |
| Outline Size | 430.4(W)×254.6(H) ×11.4(D) mm |
| Surface | Antiglare (Haze 25%), Hard coating (3H) |
| Brightness | 500 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Display Mode | ADS, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 14 (Typ.)(G to G) |
| Display Colors | 16.7M 99% sRGB |
| Lamp Type | 6S4P WLED , 50K hours , Without Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 1.30Kgs (Typ.) |
| Signal Interface | LVDS (1 ch, 8-bit) , 30 pins Connector |
| Input Voltage | 5.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| DV185WHM-NM2 high brightness 500 nit 1366*768 HD BOE lcd Screen panel for Digital Signage | |
DV185WHM-NM2 Warning:
*Installation guide not included, We are not responsible for any damage caused by installation of this accessory, please be sure you know how to install it before bid,Thank you for your kind understanding!
*We just can guarantee the one you received that will be compatible with your tablet,
*Please DO NOT buy if you do not accept an A+ grade compatible touch screen digitizer with different flex cable numbers as our title/description/photo states is out of supply in the market, thank you!
1.Each screen is tested before shipping & 100% working;Repair/Replacing old, broken, cracked,damaged faulty screen.
2.After receiving the goods, do not tear the film, do not stick the glue on the back, test the machine first, remove the old screen, insert the new screen, and check whether the sensitivity is normal. Please be sure to try the machine first. Make sure the quality is ok. Install again.it is easy to burn the motherboard and screen, we are not responsible.
3.before connection test the power must be disconnected ,Otherwise it will burn the motherboard and screen easily.If it doesn't work, we won't be responsible.
DV185WHM-NM2 Shippment & Packing
DV185WHM-NM2 About Shipment:
1. Singapore Post is good for most customers as no custom duty normally and with 15-60 days delivery time,DHL and UPS is Fast (3-8days delivery), but it may cause custom duty.
2.We don't bear any addtional import duties , taxes in parcel destination country, and shipping company will llect it from buyer upon delivery.
3.Declare value and name, we declare down $65 by default as gift if you have special request then please leave notes in the order,we could declare lowest value $10
4. Due to stock status and time differences, we will choose to ship your items from our first available warehouse for fast delivery.
5. All parcels shipped via normal post(CN post, SG post) are limited weight within 2kg. so if your parcel overweight,we will arrange your parcel via 2 parcels.
DV185WHM-NM2 Our Guarantee:
You Satisfaction is our # 1 Goal!
100% satisfaction guarantee!
It is our commitment to make sure you are 100% satisfied with you purchase
Nont: shiping by China air mail very solw. If you need shippin the fast HongKong Air mail, only add a few cost .
or shipping by DHL / fedex / Ems ..
Thank you very much for your continued support of our stores! We will work harder to provide a good service to every customer. Thank you!
DV185WHM-NM2 FAQ:
Q: If I place order now,when will you ship the goods of DV185WHM-NM2 ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: How long will I receive my goods DV185WHM-NM2 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: Can you give me a discount if I need a large quantity of DV185WHM-NM2 ?
A: Of course!If you make a large order, we will give you a discount.
Q: Can I pay my order of DV185WHM-NM2 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
