Kyocera 33 pins lcd panel TCG057VGLCS-H50 5.7 inch screen lcd display 640*480 lcd module
Product Details:
| Place of Origin: | China |
| Brand Name: | Kyocera |
| Model Number: | TCG057VGLCS-H50 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | TCG057VGLCS-H50 | Diagonal Size: | 5.7" |
|---|---|---|---|
| Resolution: | 640(RGB)×480, VGA 141PPI | Active Area: | 115.2(W)×86.4(H) Mm |
| Bezel Opening: | 118.4(W)×89.6(H) Mm | Outline Size: | 144(W)×104.8(H)×13.5(D) Mm |
| Response Time: | 10/25 (Typ.)(Tr/Td) | Operating Mode: | TN, Normally White, Transmissive |
| Weight: | 210g (Typ.) | Designed For: | Industrial |
Product Description
Kyocera 33 pins lcd panel TCG057VGLCS-H50 5.7 inch screen lcd display 640*480 lcd module
TCG057VGLCS-H50 Product details :
| Kyocera LCD SCREEN TCG057VGLCS-H50 | |
|---|---|
| Panel Brand | Kyocera |
| Panel Model | TCG057VGLCS-H50 |
| Panel Size | 5.7" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 640(RGB)×480 [VGA] 141PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 115.2(H)×86.4(V) mm |
| Bezel Opening | 118.4(W)×89.6(H) mm |
| Outline Size | 144(W)×104.8(H) ×13.5(D) mm |
| Surface | Glare (Haze 0%), Antireflection |
| Brightness | 800 cd/m² (Typ.) |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥5) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 10/25 (Typ.)(Tr/Td) |
| Display Colors | 262K 52% NTSC |
| Lamp Type | WLED , 50K hours , Without Driver |
| Touch Screen | Without |
| Panel Weight | 210g (Typ.) |
| Signal Interface | Parallel RGB (1 ch, 6-bit) , 33 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| Kyocera 33 pins lcd panel TCG057VGLCS-H50 5.7 inch screen lcd display 640*480 lcd module | |
TCG057VGLCS-H50 Product quality assurance:
Our product is original new , before sending the goods are tested by the engineers , ALL is OK,then they will be sended to the buyer,so you can rest assured to buy in my store.
TCG057VGLCS-H50 Shippment & Packing
TCG057VGLCS-H50 Delivery time:
We will receive orders in the 2 days after,so sending the parcelto you,Shipping time depends on the efficiency of your local post office and customs. General country will be 15-20 days will arrive,If you are in urgent need of a package,please choose DHL or EMS,usually in 7-10 days to reach.
TCG057VGLCS-H50 Attention:
1. Each screen is tested before shipping & 100% working;Repair/Replacing old, broken, cracked,damaged faulty touch screen.
2. After receiving the goods, do not tear the film, do not stick the glue on the back, test the machine first, remove the old screen, insert the new screen, and check whether the sensitivity is normal. Please be sure to try the machine first. Make sure the quality is ok. Install again.it is easy to burn the motherboard and touch screen, we are not responsible.
3.before connection test the power must be disconnected ,Otherwise it will burn the motherboard and touch screen easily.If it doesn't work, we won't be responsible.
TCG057VGLCS-H50 FAQ:
Q: How long will I receive my goods TCG057VGLCS-H50 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: Can you give me a discount if I need a large quantity of TCG057VGLCS-H50 ?
A: Of course!If you make a large order, we will give you a discount.
Q: Can I pay my order of TCG057VGLCS-H50 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: How long will I receive my goods TCG057VGLCS-H50 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
