TCG057VGLCA-G00 LCD TFT DISPLAY VGA 5.7 inch A Grade NEW LCD Screen
Product Details:
| Place of Origin: | China |
| Brand Name: | Kyocera |
| Model Number: | TCG057VGLCA-G00 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | TCG057VGLCA-G00 | Diagonal Size: | 5.7" |
|---|---|---|---|
| Resolution: | 640(RGB)×480, VGA 141PPI | Active Area: | 115.2(W)×86.4(H) Mm |
| Bezel Opening: | 118.4(W)×89.6(H) Mm | Outline Size: | 144(W)×104.8(H) ×13.5(D) Mm |
| Brightness: | 300 Cd/m² (Typ.) | Contrast Ratio: | 500 : 1 (Typ.) (TM) |
| Weight: | 210g (Typ.) | Application: | Industrial |
Product Description
TCG057VGLCA-G00 LCD TFT DISPLAY VGA 5.7 inch A Grade NEW LCD Screen
TCG057VGLCA-G00 Product details :
| Kyocera LCD SCREEN TCG057VGLCA-G00 | |
|---|---|
| Panel Brand | Kyocera |
| Panel Model | TCG057VGLCA-G00 |
| Panel Size | 5.7" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 640(RGB)×480 [VGA] 141PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 115.2(H)×86.4(V) mm |
| Bezel Opening | 118.4(W)×89.6(H) mm |
| Outline Size | 144(W)×104.8(H) ×13.5(D) mm |
| Surface | Glare (Haze 0%) |
| Brightness | 300 cd/m² (Typ.) |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥5) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 10/25 (Typ.)(Tr/Td) |
| Display Colors | 262K 50% NTSC |
| Lamp Type | WLED , 50K hours , Without Driver |
| Frequency | 55Hz |
| Touch Screen | Without |
| Panel Weight | 210g (Typ.) |
| Signal Interface | Parallel RGB (1 ch, 6-bit) , 33 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| TCG057VGLCA-G00 LCD TFT DISPLAY VGA 5.7 inch A Grade NEW LCD Screen | |
TCG057VGLCA-G00 Attention:
We recommend removing the old screen before ordering. Please provide your LCD model and machine model before purchasing. We need to reconfirm whether you have purchased the correct model.
Compatible models will be sent! Maybe different from the models in the title, but they are 100% compatible! If you need the exact model, please contact us before purchasing.
Please confirm whether your LCD screen can be separated from the front cover of the machine. If it can be separated, you can purchase a liquid crystal display. If separation is not possible, you need to purchase a LCD screen assembly with a front cover. To avoid purchasing the wrong product, please reconfirm whether you need a single LCD screen or assembly.
TCG057VGLCA-G00 Shippment & Packing
TCG057VGLCA-G00 Shipment:
1. We will sent the items within 2-5days (working days, Not holiday seasons)after the payment being confirmed by the platform.
2.The shipment by China Post Registered Air Mail for less than 2kg goods in 15-25 working days, If you need the item urgently, please contact us for express shipping.
We will calculate the express shipping cost for you.
3. When you receive the items you ordered, in 24 hours, please check it carefully.Please contact us directly if you have any problems.
4.If you have not got it within the shipping time,please contact us without hesitation. We will check it for you with the post office and customs.
TCG057VGLCA-G00 Returns:
We do our best to serve our customers the best that we can.We will refund you if you return the items within 15 days of your receipt of the items for any reason. However, the buyer should make sure that the items returned are in their original conditions. If the items are damaged or lost when they are returned, the buyer will be responsible for such damage or loss, and we will not give the buyer a full refund.The buyer should try to file a claim with the logistic company to recover the cost of damage or loss.
TCG057VGLCA-G00 FAQ:
Q: Do you accept sample orders of TCG057VGLCA-G00 ?
A: Of course! Sample order is welcome.
Q: Can I pay my order of TCG057VGLCA-G00 vai credit card?
A: Yes! You can use your credit card through your Paypal account.
Q: How long is the warranty ?
A: We offer 90 days warranty.
Q: If I place order now, when will you ship the goods of TCG057VGLCA-G00 ?
A: The order will be shipped within 2-3 working days after received your payment.
