Industrial LCD Panel Display

NL10276BC30-33D Original A+ Grade 15.0 inch LCD Screen Display for Industrial Equipment

All Category

Floor Standing Digital Signage

NL10276BC30-33D Original A+ Grade 15.0 inch LCD Screen Display for Industrial Equipment

Brand Name:	NEC
Model Number:	NL10276BC30-33D
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model P/N:

NL10276BC30-33D

Diagonal Size:

15.0"

Resolution:

1024(RGB)×768, XGA 85PPI

Active Area:

304.128(W)×228.096(H) Mm

Bezel Opening:

307.4(W)×231.3(H) Mm

Outline (mm):

326.5×253.5×12 (H×V×D)

Luminance:

400 Cd/m² (Typ.)

Response:

3/15 (Typ.)(Tr/Td) Ms

Mass:

0.97/1.05Kgs (Typ./Max.)

Used For:

Industrial

Supply Ability:

100000 Unit/Units per Month

Product Description

NL10276BC30-33D Original A+ Grade 15.0 inch LCD Screen Display for Industrial Equipment

NL10276BC30-33D Product details :

NEC LCD Screen NL10276BC30-33D
Manufacturer	NEC
Model Name	NL10276BC30-33D
Screen Size	15.0 inch
Panel type	a-Si TFT-LCD, LCM
Number of pixels	1024(RGB)*768, XGA, 85PPI
Pixel layout	RGB vertical bar
Display area	304.128(W)*228.096(H) mm
Viewable area	307.4(W)*231.3(H) mm
physical dimension	326.5(W)253.5(H) 12(D) mm
Surface treatment	Matte, Hard coating (3H)
Panel brightness	400 cd/m² (Typ.)
Contrast	500:1 (Typ.) (TM)
Viewing angle	80/80/80/80 (Typ.)(CR≥10)
Operating mode	TN, normally white display, transmissive
Reaction time	3/15 (Typ.)(Tr/Td) ms
Display color	16.7M, 50% NTSC
type of light source	2 pcs CCFL, without driver
working frequency	60Hz
touch screen	No touch
Panel weight	0.97/1.05Kgs (Typ./Max.)
Signal interface	LVDS (1 ch, 8-bit), 20 pins, connector
Drive screen voltage	3.3V (Typ.)
working environment	Working: -20 ~ 70 °C; Storage: -20 ~ 80 °C
NL10276BC30-33D Original A+ Grade 15.0 inch LCD Screen Display for Industrial Equipment

NL10276BC30-33D Payment:

When buying on ALI, your payments are protected by Escrow. Track your order at any stage of delivery online and feel secure that payment will only be released to the supplier after you confirm receipt of your order. With Escrow, your credit card details are never exposed.

NL10276BC30-33D Shippment & Packing

NL10276BC30-33D Original A+ Grade 15.0 inch LCD Screen Display for Industrial Equipment 0

NL10276BC30-33D Note:

Dear Brazil customers ,

Due to your country customs rule,When you place an order , Please write receiver full name and correct CPF , And we have to declare real price on customs invoice , thanks for your understand!

We have more than 12 years experience on lcd displays filed . Our LCD Display will be tested ok before shipping . So it is very safe for you to do lcd display business with us .

NL10276BC30-33D About Shipping:

- Please provide the full name of consignee and detailed address for shipping.

- We only ship according to the delivery address in the order, if you want to change the shipping address, please contact me in advance.

- NOTICE: The buyer is responsible for all additional customs fees, brokerage fees, customs duties and taxes imported into your country.

NL10276BC30-33D FAQ:

Q: If I place order now,when will you ship the goods of NL10276BC30-33D ?

A: The order will be shipped within 2-3 working days after received your payment.

Q: How long is the warranty ?

A: We offer 90days warranty .

Q: How long will I receive my goods NL10276BC30-33D ?

A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.

Q: Can You declare my order of NL10276BC30-33D to a lower price in commercial invoice for customs ?

A: Yes , we can . pls inform us before shipping .
