10.4 inch 800*600 NL8060BC26-35C tft screen lcd display tft lcd display module tft lcd panel

Brand Name:	NEC
Model Number:	NL8060BC26-35C
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model P/N:

NL8060BC26-35C

Diagonal Size:

10.4"

Resolution:

800(RGB)×600, SVGA 96PPI

Active Area:

211.2(W)×158.4(H) Mm

Bezel Opening:

215.4(W)×161.8(H) Mm

Outline Size:

243(W)×185.1(H) ×11(D) Mm

Brightness:

800 Cd/m² (Typ.)

Response Time:

3/15 (Typ.)(Tr/Td)

Weight:

475/500g (Typ./Max.)

Application:

Industrial

Supply Ability:

100000 Unit/Units per Month

Product Description

10.4 inch 800*600 NL8060BC26-35C tft screen lcd display tft lcd display module tft lcd panel

NL8060BC26-35C Product details :

NEC LCD Screen NL8060BC26-35C
Manufacturer	NEC
Model Name	NL8060BC26-35C
Screen Size	10.4 inch
Panel type	a-Si TFT-LCD, LCM
Number of pixels	800(RGB)*600, SVGA, 96PPI
Pixel layout	RGB vertical bar
Display area	211.2(W)*158.4(H) mm
Viewable area	215.4(W)*161.8(H) mm
physical dimension	243(W)185.1(H) 11(D) mm
Surface treatment	Clear, Hard coating (2H), anti-reflection treatment
Panel brightness	800 cd/m² (Typ.)
Contrast	900:1 (Typ.) (TM)
Viewing angle	80/80/80/80 (Typ.)(CR≥10)
Operating mode	TN, normally white display, transmissive
Best perspective	6 o'clock
Reaction time	3/15 (Typ.)(Tr/Td)
Display color	262K/16.7M, 40% NTSC
type of light source	4 strings WLED, 70K hours, optional
working frequency	60Hz
touch screen	No touch
Panel weight	475/500g (Typ./Max.)
Signal interface	LVDS (1 ch, 6/8-bit), 20 pins, connector
Drive screen voltage	3.3V (Typ.)
working environment	Work: -30 ~ 80 °C; Storage: -30 ~ 80 °C; Vibration resistance: 2.0G (19.6 m/s²)
*10.4 inch 800600 NL8060BC26-35C tft screen lcd display tft lcd display module tft lcd panel**

NL8060BC26-35C Product Description:

1: To Repair for Faulty Screen, Dead Pixels , Touch is not sensitive, Cracked Broken Touch Screen Problems.

2: Full Tested 100% Working By Real equipment before Shipping

3: Not supply the disassembly installation instructions and Tools

4: Please match your original screen with the image & description we have provided in this listing. If not sure. Contact with us to Confirm

5: We reserve the right to ship COMPATIBLE screens (part # or manufacturers may not be the same but 100% compatibility is guaranteed)

NL8060BC26-35C Shippment & Packing

10.4 inch 800*600 NL8060BC26-35C tft screen lcd display tft lcd display module tft lcd panel 0

NL8060BC26-35C Warm Reminder:

To Brazil buyers, Need to offer usCNPJ or CPFif ship the goods by DHL/FEDEX/EMS.

To Russia buyers, The goods only can be shipped byEMS/ePacket, The buyer need to offerfull name of receiver!

The Duty or custom fees is depend on BUYER country, Not Seller! If need declare low value when shipping , Please advise us in time !

To remote areas buyers , If ship the order by FEDEX/DHL , Need to add extra fee USD30.00, Hope buyer can understand us.

NL8060BC26-35C Reminder :

Our price is not including any customs tax / fee in the destination . You need to pay some tax / fee or not , when the goods get Clearance Customs in the destination Customs , It depends the laws in the destination country .

If you have any needs, pls don't hesitate to contact us, we will try our best to help you, hope you can have a happy shopping with us. Best regards!

NL8060BC26-35C FAQ:

Q: If I place order now,when will you ship the goods of NL8060BC26-35C ?

A: The order will be shipped within 2-3 working days after received your payment.

Q: How can I trace my order of NL8060BC26-35C ?

A: we will give you tracking number then you can trace your order from website.

Q: Can you give me a discount if I need a large quantity of NL8060BC26-35C ?

A: Of course!If you make a large order, we will give you a discount.

Q: Can I pay my order of NL8060BC26-35C via credit card ?

A: Yes!you can use your credit card through your Paypal account.
