10.1 Laptop 40pin WLED LVDS LCD Touch Panel Display B101AW06 V1 HW2A
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | B101AW06 V1 HW2A |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | B101AW06 V1 HW2A | Diagonal Size: | 10.1" |
|---|---|---|---|
| Resolution: | 1024(RGB)×600 [WSVGA]117PPI | Active Area: | 222.72(W)×125.28(H) Mm |
| Outline Size: | 243(W)×146.5(H) ×3.6(D) Mm | Brightness: | 200 Cd/m² (Typ.) |
| Viewing Angle: | 45/45/15/35 (Typ.)(CR≥10) | Number Of: | 262K, 45% NTSC |
| Shape Style: | Flat (PCBA Flat, T3.4~4.0mm) | Application: | Netbook PC |
| High Light: | LVDS LCD Touch Panel Display,Laptop LCD Touch Panel Display,B101AW06 V1 HW2A Laptop LCD Display |
||
Product Description
10.1 Laptop 40pin WLED LVDS LCD Touch Panel Display B101AW06 V1 HW2A
10.1 Laptop LCD 40pin LCD 1024*600 WLED LVDS B101AW06 V1 HW2A
B101AW06 V1 HW2A Product details :
| AUO LCD SCREEN B101AW06 V1 HW2A | |
| Panel Brand | AUO |
| Panel Model | B101AW06 V1 HW2A |
| Panel Size | 10.1" |
| Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 1024(RGB)×576 WSVGA 117PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 222.72(H)×125.28(V) mm |
| Bezel Opening | 225.72(H)×128.28(V) mm |
| Outline Size | 243 × 146.5 × 3.6 (H×V×D)mm |
| Surface | Glare (Haze 0%), Hard coating (3H), Reflection 4.3% |
| Brightness | 200 cd/m² (Typ.) |
| Contrast Ratio | 400 : 1 (Typ.) [Transmission] |
| Viewing Angle | 45/45/15/35 (Typ.) (CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 9/7 (Typ.)(Tr/Td) ms |
| Display Colors | 262K , 45% NTSC |
| Lamp Type | WLED , 10K hours, with LED driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Shape Style | Flat (PCBA Flat, T3.4~4.0mm) |
| Application | Netbook PC |
| Signal Interface | LVDS (1 ch, 6-bit) , 40 pins , terminal |
| Input Voltage | 3.3V (Typ.) |
| Environment | Storage temperature: -20 ~ 60 °C Operating temperature: 0 ~ 50 °C |
| 10.1 Laptop LCD 40pin LCD 1024*600 WLED LVDS B101AW06 V1 HW2A | |
B101AW06 V1 HW2A Friendly Reminder :
We provide a wide variety of LCD screens, touch screens, inverters and other accessories.
Many of the original LCD screen has been discontinued, we sell the Used ones of great working condition.
If you are not sure whether the product is the one you need or if you need more, please contact me before ordering.
B101AW06 V1 HW2A About Shipping:
We will test them strictly before shipping.
We will ship it in 3 working days after your paying.Buyer is responsible for customs duty fee.
It usually takes 10-45 business days for international shipping.If you don't receive the parcel for a long time,pls contact with us.
B101AW06 V1 HW2A Payment:
1:We receive AliExpress payments and papal payments. please make sure your address OK.
2: Payment must be made within 48 hours of the auction end time.
3: Non-Paying bidders will be reported.
B101AW06 V1 HW2A Tips that Will help:
For Brazil buyers, if you select Express shipping, like FED DHL UPS Ect. Please do provide company name and CNPJ number or CPF Number.
Please check your messages often, we may have some issues need your confirmation before shipping.
Please provide your FULL NAME for shipping.
Make the selection if the product has parameters, or note in the order.
Chile, Argentina buyers please provide your Tax number for express shipping like UPS.
The "Estimated Delivery Time" given by aliexpress is NOT correct, NOT our guaranteed time.
Postal mail is cheap but not fast, especially for some remote countries. If you are urgent, please inquiry faster methods.
If ship by express, make sure you are NOT in remote area, or extra costs needed, and please note that it is for remote pleace delivery .
Standard batteries, liquid and other prohibited parts are usually removed before shipping if your item are these , we may shipped by Special Line which will charged extra dollars
Customs, Duties and Import Fees are the buyer's responsibilities. We are not responsible for customs delays or any duties, tariffs, Value-Added Tax (VAT) or other fees which may be incurred with your purchase. Be know your customs policy.
B101AW06 V1 HW2A Return& Refund:
Please read the item description and check the pictures carefully before bidding.
Refund or Return is available if the item arrived broken,not as described or does not do what it's supposed to.
Return items must have all original packaging and in good condition.
B101AW06 V1 HW2A FAQ:
Q: What happen if the B101AW06 V1 HW2A I receive can't work ?
A: The B101AW06 V1 HW2A will be tested strictly before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel.
Q: Can You declare my order of lcd panel B101AW06 V1 HW2A at a very low value ?
A: Yes , we can . pls inform us before shipping .
Q: How long is the warranty of B101AW06 V1 HW2A ?
A: 90days warranty .
Q: Are you manufactory or trade company ?
A: We are a Trade Company , We are LCD panel professional distributors ,We have own warehouse and inventory. Our goal is to provide our customers with the best products.
B101AW06 V1 HW2A Shippment & Packing
