NL6448BC33-74 LCD Display Screen PANEL 10.4 inch 640(RGB)*480 for Industrial
Product Details:
| Place of Origin: | China |
| Brand Name: | NEC |
| Model Number: | NL6448BC33-74 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | NL6448BC33-74 | Diagonal Size: | 10.4" |
|---|---|---|---|
| Resolution: | 640(RGB)×480, VGA 76PPI | Active Area: | 211.2(W)×158.4(H) Mm |
| Bezel Opening: | 215.4(W)×161.8(H) Mm | Outline Dim.: | 243(H)×185.1(V)×11(D) Mm |
| Brightness: | 450 Cd/m² (Typ.) | Contrast Ratio: | 800:1 (Typ.) (TM) |
| Weight: | 475/500g (Typ./Max.) | Application: | Industrial |
Product Description
NL6448BC33-74 LCD Display Screen PANEL 10.4 inch 640(RGB)*480 for Industrial
NL6448BC33-74 Product details :
| NEC LCD SCREEN NL6448BC33-74 | |
|---|---|
| manufacturer | NEC |
| Model Name | NL6448BC33-74 |
| screen size | 10.4” |
| Screen type | a-Si TFT-LCD , LCM |
| Resolution | 640(RGB)×480 [VGA] 76PPI |
| Pixel configuration | RGB Vertical Stripe |
| Display size | 211.2(H)×158.4(V) mm |
| physical dimension | 243(H)×185.1(V) ×11(D) mm |
| Visual size | 215.4(H)×161.8(V) mm |
| surface treatment | Clear, Hard coating (3H) |
| Brightness | 450 cd/m² (Typ.) |
| Contrast | 800:1 (Typ.) (TM) |
| Best angle | Symmetry |
| Optical mode | SA-SFT, Normally Black, Transmissive |
| Viewing angle | 88/88/88/88 (Typ.)(CR≥10) |
| Responding time | 14/16 (Typ.)(Tr/Td) |
| Number of color | 262K 50% NTSC |
| Backlight type | CCFL [2 pcs] , 50K hours , W/O Driver |
| Panel weight | 475/500g (Typ./Max.) |
| Apply to | Industrial |
| Refresh rate | 60Hz |
| Touch function | No touch |
| signal system | CMOS (1 ch, 6-bit) , 31 pins Connector |
| Supply voltage | 3.3/5.0V (Typ.) |
| Maximum rating | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| NL6448BC33-74 LCD Display Screen PANEL 10.4 inch 640(RGB)×480 for Industrial | |
NL6448BC33-74 Attention:
To avoid wrong order placed or wrong item you bought, here is something you need to read before ordering.
1.Tell us the LCD model name in your hand now ,such as : NL6448BC33-74
2.Tell us your Machine name , if you don't have the LCD model.
3.Please check the LCD screen size and resolution.
4.Please check the signal interface (14pin, 20pin, 30pin(S M L) ,40pin(S,M,L), 50pin ) and position.
Contact me if u have any question, We will respond within 24 hours.
NL6448BC33-74 Shippment & Packing
NL6448BC33-74 Shipping Information:
We will ship out your items within 1-5 business days after the payment is cleared.
Some items we supply free shipping with HK/China post, if u need it urgent, pls contact me.
Standard shipping using international Airmail, Items ship from Hongkong and it takes 7-14 working days (2-3 weeks) to receive for most area.
If you do not receive item within 30 working days (5 weeks), please contact us to investigate the case.(Brazil. Italy. 5~8 weeks)
NL6448BC33-74 Warm reminder:
The Duty or custom fees is depend on BUYER country, Not Seller!
When you place an order , Please provide a valid telephone or mobile number, Because we found that when the parcel arrive customer customs , the DHL/FEDEX/EMS feedback us that they can't get through buyer's tel/mobile .
When the parcel arrive the buyer customs , there is only several days to handle Customs clearance.
If happen that the buyer can not handle the Customs clearance and pay the customs fee in time , Our seller will not refund you .
To avoid happen , please offer valid Tel/Mobile Number , and also the e-mail , it is convenient for us to contact you by e-mail when the parcel arrive your local customs .
NL6448BC33-74 FAQ:
Q: If I place order now,when will you ship the goods of NL6448BC33-74 ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: Can I pay my order of NL6448BC33-74 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: How long is the warranty ?
A: We offer 90days warranty .
Q: How long will I receive my goods NL6448BC33-74 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
