15.6 inch LCD panel HSD156JUW2-B10 support 1920*1080 Industrial LCD screen
Product Details:
| Place of Origin: | China |
| Brand Name: | NEC |
| Model Number: | HSD156JUW2-B10 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | HSD156JUW2-B10 | Diagonal Size: | 15.6" |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080, FHD 141PPI | Active Area: | 344.16(W)×193.59(H) Mm |
| Bezel Opening: | 362.5(W)×196.2(H) Mm | Outline Size: | 363.7(W)×215.7(H) Mm |
| Brightness: | 850 Cd/m² (Typ.) | Contrast Ratio: | 1000:1 (Typ.) (TM) |
| Panel Weight: | 692g (Typ.) | Application: | Outdoor High Brightness / Automotive Display |
Product Description
15.6 inch LCD panel HSD156JUW2-B10 support 1920*1080 Industrial LCD screen
HSD156JUW2-B10 Product details :
| HannStar LCD Screen HSD156JUW2-B10 | |
|---|---|
| Brand | HannStar |
| Model P/N | HSD156JUW2-B10 |
| Diagonal Size | 15.6" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1920(RGB)×1080, FHD 141PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 344.16(W)×193.59(H) mm |
| Bezel Opening | 362.5(W)×196.2(H) mm |
| Outline Size | 363.7(W)×215.7(H) mm |
| Surface | Glare (Haze 0%), Hard coating |
| Brightness | 850 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Display Mode | IPS Pro, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 15/15 (Max.)(Tr+Td) |
| Display Colors | 16.7M 71% |
| Lamp Type | 4 strings WLED , 30K hours , Without Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 692g (Typ.) |
| Application | Outdoor High Brightness / Automotive Display |
| Signal Interface | LVDS (2 ch, 8-bit) , 50 pins Connector |
| Input Voltage | 5.0V (Typ.) |
| Environment | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| 15.6 inch LCD panel HSD156JUW2-B10 support 1920*1080 Industrial LCD screen | |
HSD156JUW2-B10 Attention:
We will send the compatible one instead if the original one out of stock. If you can't accept it, please don't make the order. Thanks for your understanding!
Note:
Before you ordered, in case of any mistake & trouble in our business, please contact us as below information for double confirming to win this deal together.
1. LCD model name in your hand now.
2. Send above information to us and we will respone you within 24 hours for quick and right deal, thanks!
HSD156JUW2-B10 Shippment & Packing
HSD156JUW2-B10 Warm Reminder:
To Brazil buyers, Need to offer us CNPJ or CPF if ship the goods by DHL/FEDEX/EMS.
To Russia buyers, The goods only can be shipped by EMS/ePacket, The buyer need to offer full name of receiver!
The Duty or custom fees is depend on BUYER country, Not Seller! If need declare low value when shipping , Please advise us in time !
To remote areas buyers , If ship the order by FEDEX/DHL , Need to add extra fee USD30.00, Hope buyer can understand us.
HSD156JUW2-B10 Package Damage:
If you find that the package has been damaged when you receive , please contact the courier or the local post office immediately to issue a package damage certificate. At the same time, please do not file a dispute before contacting us, because we have more experience to protect your benefits fully.
HSD156JUW2-B10 FAQ:
Q: Can I pay my order of HSD156JUW2-B10 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: Can you give me a discount if I need a large quantity of HSD156JUW2-B10 ?
A: Of course!If you make a large order, we will give you a discount.
Q: Can You declare my order of HSD156JUW2-B10 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: How long will I receive my goods HSD156JUW2-B10 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
