NL6448BC33-70D 10.4 INCH INDUSTRIAL LCD DISPLAY 640X480 TTL 31 PINS LCD SCREEN
Product Details:
| Place of Origin: | China |
| Brand Name: | NEC |
| Model Number: | NL6448BC33-70D |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | NL6448BC33-70D | Diagonal Size: | 10.4" |
|---|---|---|---|
| Resolution: | 640(RGB)×480, VGA 76PPI | Active Area: | 211.2(W)×158.4(H) Mm |
| Bezel Opening: | 215.4(W)×161.8(H) Mm | Outline Dim.: | 243 × 185.1 × 11 (H×V×D) |
| Luminance: | 450 Cd/m² (Typ.) | Response: | 3/15 (Typ.)(Tr/Td) Ms |
| Mass: | 475/500g (Typ./Max.) | Used For: | Industrial |
Product Description
NL6448BC33-70D 10.4 INCH INDUSTRIAL LCD DISPLAY 640X480 TTL 31 PINS LCD SCREEN
NL6448BC33-70D Product details :
| NEC LCD Screen NL6448BC33-70D | |
|---|---|
| Manufacturer | NEC |
| Model Name | NL6448BC33-70D |
| Screen Size | 10.4 inches |
| Panel type | a-Si TFT-LCD, LCM |
| Number of pixels | 640(RGB)×480, VGA, 76PPI |
| Pixel layout | RGB vertical bar |
| Display area | 211.2(W)×158.4(H) mm |
| Viewable area | 215.4(W)×161.8(H) mm |
| physical dimension | 243(W)×185.1(H) ×11(D) mm |
| Surface treatment | Matte, Hard coating (3H) |
| Panel brightness | 450 cd/m² (Typ.) |
| Contrast | 900:1 (Typ.) (TM) |
| Viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| Operating mode | TN, normally white display, transmissive |
| Reaction time | 3/15 (Typ.)(Tr/Td) ms |
| Display color | 262K, 40% NTSC |
| type of light source | 3 strings WLED, 70K hours, without driver |
| working frequency | 60Hz |
| touch screen | No touch |
| Panel weight | 475/500g (Typ./Max.) |
| Signal interface | CMOS (1 ch, 6-bit), 31 pins, connector |
| Drive screen voltage | 3.3/5.0V (Typ.) |
| working environment | Work: -30 ~ 80 °C; Storage: -30 ~ 80 °C; Vibration resistance: 2.0G (19.6 m/s²) |
| NL6448BC33-70D 10.4 INCH INDUSTRIAL LCD DISPLAY 640X480 TTL 31 PINS LCD SCREEN | |
NL6448BC33-70D Product Description:
1: To Repair for Faulty Screen, Dead Pixels , Touch is not sensitive, Cracked Broken Touch Screen Problems.
2: Full Tested 100% Working By Real equipment before Shipping
3: Not supply the disassembly installation instructions and Tools
4: Please match your original screen with the image & description we have provided in this listing. If not sure. Contact with us to Confirm
5: We reserve the right to ship COMPATIBLE screens (part # or manufacturers may not be the same but 100% compatibility is guaranteed)
NL6448BC33-70D Shippment & Packing
NL6448BC33-70D About transportation:
*We will ship the goods within 1-2 working days after you make the payment. We only ship according to the delivery address. If you want to change the delivery address, please contact me in advance.
*We use the fastest shipping service based on the shipping cost you pay. The transit time is usually 7-30 days and may vary by country/region. Delivery to most European, North American and Asian countries within 7-15 days. Up to 30-45 days in other countries. Provide express service (DHL/FEDEX/TNT/ARAMEX/UPS)
NL6448BC33-70D Warranty:
1.We will provide 90 days warranty.
2.Buyers are only responsible for the return shipping fees for warranty items.(In most cases,buyers will only have to return the problem components rather than the entire package.)
3.Before returning items ,please make sure you get to our return address,and writegifton the delivery sheet.Please use regular postal service and give us the tracking number.Once we receive the items,we will repair them of exchan e them ASAP.
NL6448BC33-70D FAQ:
Q: If I place order now,when will you ship the goods of NL6448BC33-70D ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: How long is the warranty ?
A: We offer 90days warranty .
Q: Can I pay my order of NL6448BC33-70D via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: How to make payment of NL6448BC33-70D ?
A: We accept T/T , Paypal , western union .
