New and original 8.4 inch 640*480 lcd Screen module NL6448BC26-20F lcd display panel
Product Details:
| Place of Origin: | China |
| Brand Name: | NEC |
| Model Number: | NL6448BC26-20F |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | NL6448BC26-20F | Diagonal Size: | 8.4" |
|---|---|---|---|
| Resolution: | 640(RGB)×480, VGA 95PPI | Active Area: | 170.88(W)×128.16(H) Mm |
| Bezel Opening: | 174.0(W)×131.4(H) Mm | Outline Size: | 200(W)×152(H) ×8.7(D) Mm |
| Surface: | Clear, Hard Coating (3H) | Brightness: | 800 Cd/m² (Typ.) |
| Panel Weight: | 330/350g (Typ./Max.) | Application: | Industrial |
Product Description
New and original 8.4 inch 640*480 lcd Screen module NL6448BC26-20F lcd display panel
NL6448BC26-20F Product details :
| NEC LCD Screen NL6448BC26-20F | |
|---|---|
| Manufacturer | NEC |
| Model Name | NL6448BC26-20F |
| Screen Size | 8.4 inches |
| Types of | a-Si TFT-LCD, LCD module |
| Resolution | 640(RGB)×480 VGA 95PPI |
| Pixel arrangement | RGB vertical bar |
| Display area | 170.88(H)×128.16(V) mm |
| physical dimension | 200(H)×152(V) ×8.7(T) mm |
| Open area | 174.0(H)×131.4(V) mm |
| Surface treatment | Clear, Hard coating (3H) |
| Display brightness | 800 cd/m² (Typ.) |
| Contrast | 1000:1 (Typ.) (transmission) |
| Response time | 3/15 (Typ.)(Tr/Td) ms |
| Viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| Display mode | TN, normally white display, transmissive |
| Support color | 262K, 40% NTSC |
| type of light source | WLED [9S4P], 50K hours, no driver |
| weight | 330/350g (Typ./Max.) |
| Frame rate | 60Hz |
| Interface Type | 31 pins CMOS (1 ch, 6-bit), connector |
| Voltage supply | 3.3/5.0V (Typ.)(VCC) |
| Application Environment | Working temperature: -20 ~ 70 °C; Storage temperature: -30 ~ 80 °C; Vibration resistance: 2.0G (19.6 m/s²) |
| New and original 8.4 inch 640*480 lcd Screen module NL6448BC26-20F lcd display panel | |
NL6448BC26-20F Terms of Service:
Thank you for reviewing the important information, I will tell you the important steps:
The screen of the machine is inside the device, you need to disassemble the machine, and then send me the screen picture (this is very important, please pay attention),And tell me the length, width, and thickness of the screen.
NL6448BC26-20F Shippment & Packing
NL6448BC26-20F Shippment:
The panel will be 100% check and test before shippment.
We will handle your order within 3-5 business day after got your order(Weekends And Holidays Excluded).
It usually takes 10-45 business days for international shipping.If you don't receive the parcel for a long time,pls contact with us.
We also can offer Expedited International Shipping(FedEx,UPS or DHL) with extra fee if you need the item urgently.
Buyer is responsible for customs duty fee.
NL6448BC26-20F Other Policies:
We are not responsible for any custom duty or import tax.
All emails will be answered within 1 business day. If you do not receive our reply, please kindly re-sent your email and we will reply to you as soon as possible.
Serious Buyer Only! Please place bid only if you agree with all the terms.
NL6448BC26-20F FAQ:
Q: How long is the warranty of NL6448BC26-20F ?
A: 90days warranty .
Q: How can I trace my order of NL6448BC26-20F ?
A: we will give you tracking number then you can trace your order from website.
Q: Can I pay my goods NL6448BC26-20F by credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: Do you accept sample orders for NL6448BC26-20F ?
A: Of course!sample order is welcome !
