6.5 inch 640*480 NL6448BC20-35F tft lcd screen module tft lcd display panel
Product Details:
| Place of Origin: | China |
| Brand Name: | NEC |
| Model Number: | NL6448BC20-35F |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | NL6448BC20-35F | Diagonal Size: | 6.5" |
|---|---|---|---|
| Resolution: | 640(RGB)×480, VGA 122PPI | Active Area: | 132.48(W)×99.36(H) Mm |
| Bezel Opening: | 135.5(W)×102.4(H) Mm | Outline Dim.: | 153(W)×118(H) Mm |
| Luminance: | 1000 Cd/m² (Typ.) | Lamp Type: | 4 Strings WLED , 70K Hours , Without Driver |
| Weight: | 150/160g (Typ./Max.) | Designed For: | Industrial / Outdoor High Brightness |
Product Description
6.5 inch 640*480 NL6448BC20-35F tft lcd screen module tft lcd display panel
NL6448BC20-35F Product details :
| NEC LCD Screen NL6448BC20-35F | |
|---|---|
| Manufacturer | NEC |
| Model Name | NL6448BC20-35F |
| Screen Size | 6.5 inch |
| Types of | a-Si TFT-LCD, LCD module |
| Resolution | 640(RGB)×480 VGA 122PPI |
| Pixel arrangement | RGB vertical bar |
| Display area | 132.48(H)×99.36(V) mm |
| physical dimension | 153(H)×118(V) mm |
| Open area | 135.5(H)×102.4(V) mm |
| Surface treatment | Clear, Hard coating (3H) |
| Display brightness | 1000 cd/m² (Typ.) |
| Contrast | 800:1 (Typ.) (transmission) |
| Response time | 3/15 (Typ.)(Tr/Td) ms |
| Viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| Display mode | TN, normally white display, transmissive |
| Support color | 262K, 40% NTSC |
| type of light source | WLED [4 strings], 70K hours, no driver |
| weight | 150/160g (Typ./Max.) |
| Frame rate | 60Hz |
| Touch technology | No touch |
| Interface Type | 31 pins CMOS (1 ch, 6-bit), connector |
| Voltage supply | 3.3/5.0V (Typ.)(VCC) |
| Application Environment | Working temperature: -30 ~ 80 °C; Storage temperature: -30 ~ 80 °C; Vibration resistance: 2.0G (19.6 m/s²) |
| 6.5 inch 640*480 NL6448BC20-35F tft lcd screen module tft lcd display panel | |
NL6448BC20-35F KINDLY REMINDER:
sometimes international delivery is highly depended on the courier company and local customs/duties. If you do not receive your item on time, please contact us immediately for further assistance. Thank you for your understanding.
NL6448BC20-35F Shippment & Packing
NL6448BC20-35F Shipping:
1.DHL/UPS/Fedex Express usually takes about 3-5 working days to the destination. And it’s about 5-8 working days by EMS or TNT. Hongkong Post Air Mail and Hongkong Post Air Parcel take 7 to 30 days to ship to the worldwide.
2.We will send the goods within 3 business days after the full payment has been confirmed. If the payment is not available, your order will be closed automatically.
NL6448BC20-35F Attention of receiving:
When receiving the products from the express company, please check the package is fineby face to face. If the package was broken or the product was broken, please refuse receiving and require taking photos as the evidence. The photos take two parts and separate into two parts. One to customer self for evidence, another to the express company who as the third part. Then when we receive the photos from the express company who give us the damaged product, we will finger out the case who take the responsibility for the damaged product.
We can`t compensation without the third party evidence
Peace of mind with 100% satisifaction Guarantee.
Good quality,competitive price and 5 years trading business experience
If the product is not defective, the buyer is responsible for returning shipping costs and insurance. There will be a 25% restocking fee for returning an item what is not defective.
NL6448BC20-35F FAQ:
Q: I do not find the LCD I am looking for in the website, what should I do ?
A: You can give us some pictures,we have a lot of LCD out of shelves.
Q: How long will I receive my goods of NL6448BC20-35F ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: How to make payment for NL6448BC20-35F ?
A: We accept T/T , Paypal , western union .
Q: What happen if the NL6448BC20-35F I receive can't work ?
A: NL6448BC20-35F will be tested strictly before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel.
