Original NL6448BC20-21D 6.5 inch LCD Screen panel for Industrial Equipment
Product Details:
| Place of Origin: | China |
| Brand Name: | NEC |
| Model Number: | NL6448BC20-21D |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | NL6448BC20-21D | Diagonal Size: | 6.5" |
|---|---|---|---|
| Resolution: | 640(RGB)×480, VGA 122PPI | Active Area: | 132.48(W)×99.36(H) Mm |
| Bezel Opening: | 135.9(W)×102.8(H) Mm | Outline Size: | 153(W)×118(H) Mm |
| Brightness: | 550 Cd/m² (Typ.) | Contrast Ratio: | 600:1 (Typ.) (TM) |
| Weight: | 165/185g (Typ./Max.) | Application: | Industrial |
Product Description
Original NL6448BC20-21D 6.5 inch LCD Screen panel for Industrial Equipment
NL6448BC20-21D Product details :
| manufacturer | NEC |
|---|---|
| model | NL6448BC20-21D |
| Diagonal size | 6.5 inch |
| Types of | a-Si TFT-LCD, LCD module |
| Resolution | 640(RGB)×480 VGA 122PPI |
| Pixel arrangement | RGB vertical bar |
| Display area | 132.48(H)×99.36(V) mm |
| physical dimension | 153(H)×118(V) mm |
| Open area | 135.9(H)×102.8(V) mm |
| Surface treatment | Matte, Hard coating (3H) |
| Display brightness | 550 cd/m² (Typ.) |
| Contrast | 600:1 (Typ.) (transmission) |
| Recommended perspective | 6 o'clock |
| Response time | 6/19 (Typ.)(Tr/Td) ms |
| Viewing angle | 80/80/80/60 (Typ.)(CR≥10) |
| Display mode | TN, normally white display, transmissive |
| Support color | 262K/16.7M, 36% NTSC |
| type of light source | WLED [6 strings], 40K hours, no driver |
| weight | 165/185g (Typ./Max.) |
| Application products | industry |
| Frame rate | 60Hz |
| Touch technology | No touch |
| Interface Type | 20 pins LVDS (1 ch, 6/8-bit), connector |
| Voltage supply | 3.3V (Typ.) |
| Application Environment | Working temperature: -20 ~ 70 °C; Storage temperature: -30 ~ 80 °C; Vibration resistance: 2.0G (19.6 m/s²) |
| Original NL6448BC20-21D 6.5 inch LCD Screen panel for Industrial Equipment | |
NL6448BC20-21D Note:
1: This product is a display screen, which needs to be installed by professionals. Please purchase with caution, thank you!
2: Purchasing this product, according to the buyer's choice of logistics, we will send it out within 48 hours, if there is a delay, please wait for the tracking information to prevail!
3: After receiving the product, if there is a problem, please contact customer service to solve it!
NL6448BC20-21D Shippment & Packing
NL6448BC20-21D About the goods:
Receive delivery company products, please check whether the parcel in good face to face. If damaged packaging or product damage, please refuse and ask the photos to prove it. Photos are divided into two parts, divided into two parts. A customer himself as evidence, the other a Courier company as a third party. Then when we received the Courier company send us the pictures of damaged products, we will find out is responsible for the damage to the product of the case. No third party evidence we can't pay for
NL6448BC20-21D RETURN:
1.If you receive a damaged or wrong item , please contact us via message , we will arrange return immediately. Please do not leave negative feedback or open any cases before contacting us.
2.Return is accepted within 30 days after receiving of the item.
3.When doing the return , please pack the product safely like how we do in the original package. As the screens are very fragile.Please do not use other package.
4.Buyer is responsible for the return shipping cost in the cases of buyer purchasing wrong products , wrong size ,etc..
NL6448BC20-21D FAQ:
Q: Can I pay my order of NL6448BC20-21D via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: Can You declare my order of NL6448BC20-21D to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: Can you give me a discount if I need a large quantity of NL6448BC20-21D ?
A: Of course!If you make a large order, we will give you a discount.
Q: How long will I receive my goods NL6448BC20-21D ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
